Commissioning
Configuring the digital inputs and outputs
l
169
EDBCSXP064 EN 8.0
Code
Possible settings
IMPORTANT
No.
Designation
Lenze/
{Appl.}
Selection
[C4011] DigIn_map
0
Assignment of the digital inputs
X6/DI1 ... DI4
Acceptance only if the controller
is inhibited (status word
Stat1.Imp = 1).
^ 168
DI1
DI2
DI3
DI4
Ix: Input x is not assigned with a
function.
JogCW: Manual jog CW
JogCCW: Manual jog CCW
Ln: Limit switch in negative
direction
Lp: Limit switch in positive
direction
PNo1: Selection of positioning
profile bit 2
0
PNo2: Selection of positioning
profile bit 2
1
PNo4: Selection of positioning
profile bit 2
2
PNo8: Selection of positioning
profile bit 2
3
Penb: Positioning profile
activated (enable)
Qsp: Quick stop (QSP)
R: TRIP−RESET
Ref: Reference switch
TP: Touch probe input
0
Ln Ref TP Lp
1
PNo1 PNo2 PNo4 PNo8
2
PNo1 PNo2 PNo4 PEnb
3
PNo1 PNo2 R
PEnb
4
Qsp JogCW
Tp JogCCW
5
I1
I2 TP I4
6
Ln
Qsp
Penb
Lp
7
PNo1
PNo2
TP
Penb
8
PNo1
PNo2
Ref
Penb
9
Ln
PNo1
PNo2
Lp
10
Ln
JogCW
JogCCW Lp
11
Ln
Ref
Penb
Lp
12
Ln
Ref
Qsp
Lp
13
Ln
Qsp
TP
Lp
[C4012] DigOut_map
0
Assignment of digital output
X6/DO1
Acceptance only if the controller
is inhibited (status word
Stat1.Imp = 1).
^ 168
0
RDY
Rdy: Drive is ready for operation.
