Code table
l
393
EDBCSXP064 EN 8.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C2454
Alternative node addresses for
CANaux_IN/CANaux_OUT (CAN
bus interface X14)
^ 271
1 CANa addr.
129
1
{1}
512 CANaux1_INaddress 2
2 CANa addr.
1
CANaux1_OUTaddress 2
3 CANa addr.
257
CANaux2_INaddress 2
4 CANa addr.
258
CANaux2_OUTaddress 2
5 CANa addr.
385
CANaux3_IN address 2
6 CANa addr.
386
CANaux3_OUT address 2
C2455
Identifier for
CANaux_IN/CANaux_OUT (CAN
bus interface X14)
Read only
^ 429
1 CANa Id
1
{1}
2047 Identifier CANaux1_IN
2 CANa Id
Identifier CANaux1_OUT
3 CANa Id
Identifier CANaux2_IN
4 CANa Id
Identifier CANaux2_OUT
5 CANa Id
Identifier CANaux3_IN
6 CANa Id
Identifier CANaux3_OUT
C2456
CAN time settings for CAN bus
interface X14 (CAN−AUX)
^ 274
1 CANa times
3000
0
{1 ms}
65000 CAN−AUX boot−up time:
Delay time after mains
connection for initialisation
through the master.
2 CANa times
0
CANaux2...3_OUT cycle times:
Factor for the task time to send
process data telegram.
0 = event−controlled
transmission
3 CANa times
0
4 CANa times
20
Delay time for initial
transmission of the process data
objects 2 and 3 after the CAN bus
changed to "Operational"
C2457
Monitoring time for
CANaux1...3_IN (CAN bus
interface X14)
^ 297
1 CE monit time
3000
1
{1 ms}
65000 CE11 monitoring time
2 CE monit time
3000
CE12 monitoring time
3 CE monit time
3000
CE13 monitoring time
C2458 Reset node
0
Resetting a node
(CAN bus interface X14)
^ 276
0
No function
1
CAN−AUX reset
C2459 CANa state
CAN bus status (CAN bus
interface X14)
Read only
^ 286
0
Operational
1
Pre−operational
2
Warning
3
Bus off
