Commissioning
Controller enable (CINH = 0)
6
l
241 EDBCSXP064 EN 8.0
6.27 Controller enable (CINH = 0)
The controller will only be enabled internally if no signal sources relevant for the controller
inhibit (CINH) are activated (i.e. CINH−signal sources = 0).
The following table describes the signal sources for the controller inhibit (CINH) /
controller enable:
Source of the
Controller inhibit Controller
inhibit Controller
enable Comment
Terminal X6/SI1
(Controller inhibit) LOW level
(0 ... +4 V) HIGH level
(+13 ... +30 V) For controller enable, both input terminals
(X6/SI1 AND X6/SI2) must be controlled
with HIGH level.
Terminal X6/SI2
(Pulse inhibit) LOW level
(0 ... +4 V) HIGH level
(+13 ... +30 V)
Control bit Ctrl1.Cinh
in the control word
"Ctrl1" Ctrl1.Cinh = 1 Ctrl1.Cinh = 0 see ^ 158
The control word "Ctrl1" is described via the
set control interface.
The control interface is selected under
C4010. The following are available:
l MotionBus (CAN)
l System bus (CAN−AUX)
l Fieldbus via AIF interface
l Code C4040
If required, see the documentation on the
corresponding fieldbus module, if control
via AIF interface.
C0040
(Controller inhibit) C0040 = 0 C0040 = 1
STOP/RUN key on
the operating
module/keypad XT s key u key Inhibiting with s key is only possible if
the s key is assigned with "CINH" via
C0469.
Set C0135.Bit09 = 1 via the
s key.
Set C0135.Bit09 = 0 via the u key.
Fault/message l in case of TRIP
l in case of
message
TRIP−RESET For check see ^ 337.
Control bit09
(controller inhibit
CINH) in the "DCTRL
control word" under
C0135 C0135.Bit09 = 1 C0135.Bit09 = 0
Function button
and in the
Global Drive Control
(GDC) Button Button GDC writes to C0135.Bit09 via parameter
data channel.
(start drive) serves to set
C0135.Bit09 = 1.
(stop drive) serves to set
C0135.Bit09 = 0.
Brake logic CINH is controlled
internally by brake
logic CINH is not
controlled internally
by brake logic Display through C0183 = 122
(CINH−intern1 (brake logic))
