Configuration
Selection lists
Selection list 3: Angle signals
8
8.5
8.5.3
l
8.5−9 EDSVS9332K EN 8.0−07/2013
Parameter Angle signal ( E)
19526 FCODE−PH−474/6
19527 FCODE−PH−474/7
19528 FCODE−PH−474/8
19529 FCODE−PH−474/9
19530 FCODE−PH−474/10
19601 FCODE−MASTER−1476/1
19602 FCODE−MASTER−1476/2
19603 FCODE−MASTER−1476/3
19604 FCODE−MASTER−1476/4
19605 FCODE−MASTER−1476/5
19606 FCODE−MASTER−1476/6
19607 FCODE−MASTER−1476/7
19608 FCODE−MASTER−1476/8
19609 FCODE−MASTER−1476/9
19610 FCODE−MASTER−1476/10
19611 FCODE−MASTER−1476/11
19612 FCODE−MASTER−1476/12
19613 FCODE−MASTER−1476/13
19614 FCODE−MASTER−1476/14
19615 FCODE−MASTER−1476/15
19616 FCODE−MASTER−1476/16
19701 FCODE−SLAVE−1477/1
19702 FCODE−SLAVE−1477/2
19703 FCODE−SLAVE−1477/3
19704 FCODE−SLAVE−1477/4
19705 FCODE−SLAVE−1477/5
19706 FCODE−SLAVE−1477/6
19707 FCODE−SLAVE−1477/7
19708 FCODE−SLAVE−1477/8
19709 FCODE−SLAVE−1477/9
19710 FCODE−SLAVE−1477/10
19711 FCODE−SLAVE−1477/11
19712 FCODE−SLAVE−1477/12
19713 FCODE−SLAVE−1477/13
19714 FCODE−SLAVE−1477/14
19715 FCODE−SLAVE−1477/15
19716 FCODE−SLAVE−1477/16
19720 FCODE−Z−1478/1
19721 FCODE−Z−1478/2
19722 FCODE−Z−1478/3
19723 FCODE−Z−1478/4
19724 FCODE−Z−1478/5
19725 FCODE−Z−1478/6
20103 CAN−IN1.D1
20201 CAN−IN2.D1
20202 CAN−IN2.D2
20301 CAN−IN3.D1
Parameter Angle signal ( E)
20302 CAN−IN3.D2
25103 AIF−IN.D1
25104 AIF−IN.D2
