Lenze EVS9332xK - Manual (Page 297)

Configuration
Code table
8
8.4
l
8.4−23 EDSVS9332K EN 8.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0517 0.00 {0.01} 1999.00 User menu
Up to 32 entries
l Under the subcode, the number of the
desired code is entered.
l Input format: xxx.yy
– xxx: Code number
– yy: Subcode number
l There is no check for existence of entered
code.
1 USER MENU 51.00 C0051/0 MCTRL−NACT
2 USER MENU 54.00 C0054/0 Imot
3 USER MENU 56.00 C0056/0 MCTRL−MSET2
4 USER MENU 46.00 C0046/0 N
5 USER MENU 49.00 C0049/0 NADD
6 USER MENU 183.0
0
C0183/0 Diagnostics
7 USER MENU 168.0
1
C0168/1 Fail no. act
8 USER MENU 86.00 C0086/0 Mot type
9 USER MENU 22.00 C0022/0 Imax current
10 USER MENU 5.00 C005/0 Signal cfg
11 USER MENU 11.00 C0011/0 Nmax
12 USER MENU 12.00 C0012/0 T
ir
13 USER MENU 13.00 C0013/0 T
if
14 USER MENU 105.0
0
C0105/0 QSP T
if
15 USER MENU 39.01 C0039/1 JOG setpoint
16 USER MENU 70.00 C0070/0 Vp speed CTRL
17 USER MENU 71.00 C0071/0 Tn speed CTRL
18 USER MENU 0 Not assigned
... ... 0 Not assigned
31 USER MENU 94.00 C0094/0 Password
32 USER MENU 3.00 C0003/0 Par save
C0520
s
IN 1000 FIXEDPHI−0 ® Selection list 4 DFSET
Configuration of input signal
C0521
s
VP−DIV 1000 FIXED0% ® Selection list 1 DFSET
Configuration of gain factor numerator
C0522
s
RAT−DIV 1000 FIXED0% ® Selection list 1 DFSET
Configuration of gearbox factor numerator
C0523
s
A−TRIM 1000 FIXED0% ® Selection list 1 DFSET
Configuration of phase trimming
C0524
s
N−TRIM 1000 FIXED0% ® Selection list 1 DFSET
Speed trimming of DFSET
C0525
s
0−PULSE 1000 FIXED0 ® Selection list 2 DFSET
Configuration of one−time zero pulse
activation
C0526
s
RESET 1000 FIXED0 ® Selection list 2 DFSET
Integrator resetting
C0527
s
SET 1000 FIXED0 ® Selection list 2 DFSET
Configuration of integrator setting
C0528 g −2 . 10 9 {1} 2 . 10 9 DFSET
1 0−PULSE A Phase difference between 2 zero pulses
2 OFFSET Offset results from C0523 × C0529 + C0252
C0529 MULTIP OFFSET 1 −20000 {1} 20000 Offset multiplier
C0530 DF
EVALUATION
0 0 With gearbox factor DFSET
Evaluation of the digital frequency
1 Without gearbox factor
C0531 ACT 0 DIV 1 1 {1} 16384 DFSET actual zero pulse divider
