Configuration
Code table
8.4
l
8.4−43
EDSVS9332K EN 8.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C0928 (C0922)
g −2147483647
{1 inc}
2147483647 REFC
Phase signal (following error)
l
1 rev = 65536 inc
C0929 (C0923)
g −199.99
{0.01 %}
199.99 REFC
Display of analog input signal
C0930
s
GEARBOX MOT
1
1
{1}
65535 REFC
Encoder−gearbox factor numerator (on the
motor side)
C0931
s
GEARBOX ENC
1
1
{1}
65535 REFC
Encoder−gearbox factor denominator (on the
encoder side)
C0932 REF MODE
0
REFC
Homing mode
0
Mode 0
Positive direction, reference switch, zero
pulse
1
Mode 1
Negative direction, reference switch, zero
pulse
6
Mode 6
Positive direction, reference switch, touch
probe
7
Mode 7
Negative direction, reference switch, touch
probe
8
Mode 8
Positive direction, touch probe
9
Mode 9
Negative direction, touch probe
20
Mode 20
Direct homing
21
Mode 21
Direct homing, store actual value
C0933 REF TRANS
0
0
1
Rising edge
Falling edge
REFC
Edge of homing signal
C0934 REF OFFSET
0
−2140000000
{1 inc}
2140000000 REFC
Home position offset
C0935 REF SPEED
2.000
0
0.0001
{0.0001
%}
100.0000 REFC
Homing speed
Speed used for homing run
The value set is the percentage value of N
max
C0936 REF TI
1.00
0.01
{0.01 s}
990.00 REFC
Homing acceleration/deceleration time
T
ir
and T
if
are identical
C0937
s
REFC−DFIN
1000 FIXEDPHI−0
® Selection list 4 REFC
Input configuration
C0938 (C0937)
g
REFC
Display of input signal
C0940 NUMERATOR
1
−32767
{1}
32767 CONV1
Numerator
C0941 DENOMITATOR
1
1
{1}
32767 CONV1
Denominator
C0942
s
CONV1−IN
1000 FIXED0%
® Selection list 1 CONV1
Configuration of analog input
C0943 (C0942)
g −199.99
{0.01 %}
199.99 CONV1
Display of analog input signal
C0945 NUMERATOR
1
−32767
{1}
32767 CONV2
Numerator
C0946 DENOMINATO
R
1
1
{1}
32767 CONV2
Denominator
C0947
s
IN
1000 FIXED0%
® Selection list 1 CONV2
Configuration of analog input
