Configuration
Code table
8.4
l
8.4−28
EDSVS9332K EN 8.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C0644
s
à Selection list 4 PT1−2
Configuration of input signal
1 PT1−2−DFIN
1000 FIXEDPHI−0
C0645 (C0644)
g
PT1−2
Display of input signal
C0646
0
{1 rpm}
16000 PT1−2
1
5
Compensation of the phase shift
(compensation speed) when filter is on
If C0646/1 = 0 is set, the position will be lost
2
15000
Compensation of the phase shift
(compensation speed) when filter is off
If C0646/2 = 0 is set, the position will be lost
C0647
s
à Selection list 2 PT1−2
Configuration of digital input signals
1 PT1−2−DISABLE
FILTER
1000 FIXED0
LOW = filter on
HIGH = filter off
2 PT1−2−RESET
1000 FIXED0
HIGH = filter reset
C0648
g
PT1−2
Display of digital input signals
1 (C0647/1)
2 (C0647/2)
C0650 DT1−1 GAIN
1.000 −320.00
{0.001}
320.00 DT1−1
Gain
C0651 DELAY T
1.00
0.003
{0.01 s}
5.000 DT1−1
Time constant
C0652
s
IN
1000 FIXED0%
® Selection list 1 DT1−1
Configuration of analog input signal
C0653 SENSIBILITY
1
1
2
3
4
5
6
7
15−bit
14−bit
13−bit
12−bit
11−bit
10−bit
9−bit
DT1−1
Sensitivity
C0654 (C0652)
g −199.99
{0.01 %}
199.99
C0655 NUMERATOR
1
−32767
{1}
32767 CONV5
Numerator
C0656 DENOMINATO
R
1
1
{1}
32767 CONV5
Denominator
C0657
s
IN
1000 FIXED0%
® Selection list 1 CONV5
Configuration of analog input signal
C0658 (C0657)
g −199.99
{0.01 %}
199.99 CONV5
Display of analog input signal
C0661
s
IN
1000 FIXED0%
® Selection list 1 ABS1
Configuration of analog input signal
Input for absolute value generator
C0662 (C0661)
g −199.99
{0.01 %}
199.99 ABS1
Display of analog input signal
C0671 RFG1 TIR
0.000 0.000
{0.01 s}
999.900 RFG1
Acceleration time Tir
C0672 RFG1 TIF
0.000 0.000
{0.01 s}
999.900 RFG1
Deceleration time Tif
C0673
s
IN
1000 FIXED0%
® Selection list 1 RFG1
Configuration of analog input signal
C0674
s
SET
1000 FIXED0%
® Selection list 1 RFG1
Configuration of analog input signal
