Lenze EVS9332xK - Manual (Page 349)

Configuration
Code table
8
8.4
l
8.4−75 EDSVS9332K EN 8.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1582
s
CONVAD2−IN 1000 FIXED0% ® Selection list 1 CONVAD2
Configuration of analog input signal
C1583 (C1582) g −32768 {1} 32767 CONVAD2
Display of analog input signal
C1590 NUMERAATOR 1 −32768 {1} 32767 CONVAPH1
Numerator
C1591 DENUMERAAT
OR
1 1 {1} 32767 CONVAPH1
Denominator
C1593
s
CONVAPH1−IN 1000 FIXED0% ® Selection list 1 CONVAPH1
Configuration of analog input signal
C1594 (C01593) CONVAPH1
Display of analog input signal
C1610 1 0 {1} 31 CONVAPH1
Division factor
C1611
s
CONVPHA2−IN 1000 FIXED0INC ® Selection list 3 CONVPHA2
Configuration of input signal
C1612 (C1611) g {1 inc.} CONVPHA2
Display of input signal
C1615 1 0 {1} 31 CONVAPH2
Division factor
C1616
s
CONVPHA3−IN 1000 FIXED0INC ® Selection list 3 CONVPHA3
Configuration of input signal
C1617 (C1616) g {1 inc.} CONVPHA3
Display of input signal
C1620
s
® Selection list 3 CONVPHAA1
Configuration of input signals
1 CONVPHAA1−P
HIN
1000 FIXED0INC
2 CONVPHAA2−P
HIN
1000 FIXED0INC
C1621 g {1 inc.} CONVPHAA1
Display of input signals
1 (C1620/1)
2 (C1620/2)
C1640
s
RESET 1000 FIXED0 ® Selection list 2 SPC1
