IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1651 FCODE1476/1 SPC2
1 SPC2−VALUE
1−1
1 Switching point output STATUS−01
2 SPC2−VALUE
1−2
1 Switching point output STATUS−01
3 SPC2−VALUE
2−1
1 Switching point output STATUS−02
4 SPC2−VALUE
2−2
1 Switching point output STATUS−02
5 SPC2−VALUE
3−1
1 Switching point output STATUS−03
6 SPC2−VALUE
3−2
1 Switching point output STATUS−03
7 SPC2−VALUE
4−1
1 Switching point output STATUS−04
8 SPC2−VALUE
4−2
1 Switching point output STATUS−04
9 SPC2−VALUE
5−1
1 Switching point output STATUS−05
10 SPC2−VALUE
5−2
1 Switching point output STATUS−05
11 SPC2−VALUE
6−1
1 Switching point output STATUS−06
12 SPC2−VALUE
6−2
1 Switching point output STATUS−06
13 SPC2−VALUE
7−1
1 Switching point output STATUS−07
14 SPC2−VALUE
7−2
1 Switching point output STATUS−07
15 SPC2−VALUE
8−1
1 Switching point output STATUS−08
16 SPC2−VALUE
8−2
1 Switching point output STATUS−08
C1652
s
SPC2−L−IN 1000 FIXED0INC ® Selection list 3 SPC2
Configuration of input signal
C1653 (C1650) g 0 1 SPC2
Display of digital input signal
C1654 (C1652) g −1073741824 {1 inc} 1073741823 SPC2
Display of input signal
C1655 MODE 0 0
1 On / off
Centre/range SPC2 mode
C1657 −30000 {1 ms} 30000 SPC2
Dead time
1 DEATH TIME 0
... ... 0
4 DEATH TIME 0
C1658 HYSTERESIS 0 −32767 {1 inc} 32767 SPC2
Hysteresis
C1659 FILTER 1 0
1
2
4
8
16 Filter off
Filter 1 ms
Filter 2 ms
Filter 4 ms
Filter 8 ms
Filter 16 ms SPC2
Filters
C1660 ACT.SEL. g 0 {1} 8 SELPH1
Display of actual selection
