Configuration, Code table – Lenze EVS9332xK User Manual
Page 340
Configuration
Code table
8.4
l
8.4−66
EDSVS9332K EN 8.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C1367
s
−214000.0000
{0.0001
s−units}
214000.0000 CCTRL, CCTRL2
1
0.000
0
Set home position
1. When using an absolute value encoder as
feedback: Enter the distance between tool
and machine zero.
2. Switch off the controller and then on
again to reinitialise the profile data.
l
The home position must only be set once.
After that, the controller is able to find the
position after mains switching.
l
The y value displayed refers to machine
zero.
2
0.000
0
Reset home position
l
Writing a "0" resets the "Set reference"
function executed under C1367/1.
l
The encoders are no longer considered to
be absolute, but relative encoders.
C1368
0
0
1
Motor mounted on the right−hand side
Motor mounted on the left−hand side
CCTRL
Motor mounting direction
C1369
1
1
{1 ms}
100 CCTRL
M−Tv−CCTRL−MOUT
Rate time for torque feedforward control
C1370
s
EXTPOL1−AIN
1000 FIXED0%
® Selection list 1 EXTPOL1
Configuration of input signals
C1371 (C1370)
g
EXTPOL1
Display of analog input signal
C1374
s
® Selection list 3 EXTPOL1/EXTPOL2
Configuration of input signals
1 EXTPOL1−PHIN
1000 FIXED0INC
2 EXTPOL2−PHIN
1000 FIXED0INC
C1375
g
{1 inc}
EXTPOL1, EXTPOL2
Display of input signals
1 (C1374/1)
2 (C1374/2)
C1379
2
1
{1 ms}
127 EXTPOL2
Maximum extrapolation cycles
C1380
10
{1 inc}
1800000000 CERR1
1
10
Hysteresis of fault signal (ERR output)
2
10
Hysteresis of warning signal (WARN output)
C1384
s
CERR1−WFAC
1000 FIXED0
® Selection list 1 CERR1
Reduction factor
+100 % = No reduction
<100 % = Reduction
>100 % = Increase
C1385 (C1384)
g
CERR1
Display of analog input signal
C1386
s
CERR1−DISABLE
1000 FIXED0%
® Selection list 1 CERR1
HIGH sets CERR1−WARN and CERR1−EER = 0
C1387 (C1386)
g
CERR1
Display of analog input signal
C1388
s
1000
® Selection list 4 CERR1
Configuration of input signals
1 CERR1−PHI−IN
FIXED0INC
Input
2 CERR1−LIM
FIXED0INC
Switching threshold; the absolute value is
generated from the input value
