Configuration
Code table
8
8.4
l
8.4−19 EDSVS9332K EN 8.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0427 DFIN
FUNCTION
0 0
1
2 2−phase
A pulse / B direction
Pulses A or B DFIN
Selection of the digital frequency signal
C0430 0.000 {0.001
ms}
2.000 Delay of the touch−probe signal
1 TP1 DELAY 0.218 Touch−probe signal at X5/E1
2 TP2 DELAY 0.218 Touch−probe signal at X5/E2
3 TP3 DELAY 0.218 Touch−probe signal at X5/E3
4 TP4 DELAY 0.218 Touch−probe signal at X5/E4
5 TP5 DELAY 0.218 Touch−probe signal at X5/E5
C0431
s
IN 5001 MCTRL−NACT ® Selection list 1 AOUT1
Configuration of analog input signal
C0432
s
OFFSET 19512 FCODE−109/1 ® Selection list 1 AOUT1
Offset configuration
C0433
s
GAIN 19510 FCODE−108/1 ® Selection list 1 AOUT1
Gain configuration
C0434 g −199.99 {0.01 %} 199.99 AOUT1
Display of analog input signals
1 (C0431)
2 (C0432)
3 (C0433)
C0436
s
IN 5002 MCTRL−MSET2 ® Selection list 1 AOUT2
Configuration of analog input signal
C0437
s
OFFSET 19513 FCODE−109/2 ® Selection list 1 AOUT2
Offset configuration
C0438
s
GAIN 19511 FCODE−108/2 ® Selection list 1 AOUT2
Gain configuration
C0439 g −199.99 {0.01 %} 199.99 AOUT2
Display of analog input signals
1 (C0436)
2 (C0437)
3 (C0438)
C0440
s
STATE−BUS 1000 ® Selection list 2 Configuration of state bus X5/ST
C0441 (C0440) g
C0443 DIGIN−OUT g 0 {1} 255 Signals at X5/E1 to X5/E5, decimal value
l Binary interpretation indicates terminal
signals
C0444 (C0118) g 0 1
C0450
s
NX 1000 FIXED0% ® Selection list 1 BRK1
Configuration of analog input signal
C0451
s
SET 1000 FIXED0 ® Selection list 2 BRK1
Configuration of digital input signal
C0452
s
SIGN 1000 FIXED0% ® Selection list 1 BRK1
Configuration of analog input signal
C0458 g −199.99 {0.01 %} 199.99 BRK1
Display of analog input signals
1 (C0450)
2 (C0452)
C0459 (C0451) g BRK1
Display of digital input signal
