Configuration
Code table
8
8.4
l
8.4−52 EDSVS9332K EN 8.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1150 FUNCTION 0 0
1
2 Load permanent
Load edge
Compare & subtract PHINT3
Function selection
C1151 CMP. VALUE 2 ×10 9 0 {1} 2000000000 PHINT3
Setting of a comparison value
C1153
s
IN 1000 FIXEDPHI−0 ® Selection list 4 PHINT3
Configuration of speed input signal
C1154
s
LOAD 1000 FIXED0 ® Selection list 2 PHINT3
Configuration of digital input signal
C1155
s
SET 1000 FIXED0INC ® Selection list 3 PHINT3
Configuration of phase input signal
C1157 (C1153) g −32767 {1} 32767 PHINT3
Display of input signal
C1158 (C1154) g PHINT3
Display of digital input signal
C1159 (C1155) g −2147483647 {1} 2147483647 PHINT3
Display of input signal
C1160
s
® Selection list 1 ASW3
Configuration of analog input signals
1 IN1 1000 FIXED0%
2 IN2 1000 FIXED0%
C1161
s
SET 1000 FIXED0 ® Selection list 2 ASW3
Configuration of digital input signal
C1162
g −199.99 {0.01 %} 199.99 ASW3
Display of analog input signals
1 (C1160/1)
2 (C1160/2)
C1163 (C1161) g ASW3
Display of digital input signal
C1165
s
® Selection list 1 ASW4
Configuration of analog input signals
1 IN1 1000 FIXED0%
2 IN2 1000 FIXED0%
C1166
s
SET 1000 FIXED0 ® Selection list 2 ASW4
Configuration of digital input signal
C1167 g −199.99 {0.01 %} 199.99 ASW3
Display of analog input signals
1 (C1165/1)
2 (C1165/2)
C1168 (C1166) g ASW4
Display of digital input signal
C1170 NUMERATOR 1 −32767 32767 CONV6
Numerator
C1171 DENOMINATO
R
1 1 {1} 32767 CONV6
Denominator
C1172
s
IN 1000 FIXED0% ® Selection list 1 CONV6
Configuration of analog input signal
C1173 (C1172) g −199.99 {0.01 %} 199.99 CONV6
Display of analog input signal
C1175
s
® Selection list 2 AND6
Configuration of digital input signals
1 IN1 1000 FIXED0
2 IN2 1000 FIXED0
3 IN3 1000 FIXED0
