Configuration
Code table
8
8.4
l
8.4−2 EDSVS9332K EN 8.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0005
s
SIGNAL CFG 1000 Signal configuration
(Predefined basic configurations)
0 COMMON Changed basic configuration
100 Empty All internal links are deleted
1000 Speed control The first two digits indicate the predefined
basic function, e.g.
l 01xxx: speed control
l 10xxx: cam profiling
The third digit indicates the additional
function:
l xx0xx: no additional function
l xx1xx: homing function
l xx2xx: clutch function
l xx3xx: switching points
l xx4xx: mains failure control
l xx8xx: mark−controlled correction of the
master value
l xx9xx: mark−controlled correction of the
actual value
The fourth digit indicates the predefined
voltage source for the control terminals:
l xxx0x: external supply voltage
l xxx1x: internal supply voltage
The fifth digit indicates the predefined device
control:
l xxxx0: terminal control
l xxxx1: RS232, RS485 or optical fibre
l xxxx3: INTERBUS or PROFIBUS−DP
l xxxx5: system bus (CAN)
10000 Cam
11000 Welding bar
12000 Cam with position storage
13000 Cam with virtual master
14000 Cam with virtual master and welding
bar
15000 Cam with virtual master and position
storage
16000 Cam with absolute master value
17000 Welding bar with absolute master
value
18000 Cam with absolute master value and
position storage
C0006
s
OP MODE à Motor control mode
1 SSC standard motor, sensorless, in star
connection à Depending on C0086
l Change of C0086 resets value to the
assigned default setting
l Change of C0006 sets C0086 = 0!
2 Asynchronous servo motor, in star
connection
3 PM servo motor, synchronous, in star
connection
11 SSC standard motor, sensorless, in
delta connection
22 Asynchronous servo motor, in delta
connection
C0009 LECOM
ADDRESS
1 1 {1} 99 LECOM device address
Bus device number for operation via interface
l 10, 20, ..., 90 reserved for broadcast to
device groups for RS232, RS485, fibre
optics.
C0011 NMAX 3000 500 {1 rpm} 16000 Max. speed Nmax
Reference value for the absolute and relative
setpoint selection for the acceleration and
deceleration times.
l For parameter setting via interface:
– Greater changes in one step should only
be made when the controller is
inhibited.
