Lenze EVS9332xK - Manual (Page 318)

Configuration
Code table
8
8.4
l
8.4−44 EDSVS9332K EN 8.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0948 (C0947) g −199.99 {0.01 %} 199.99 CONV2
Display of analog input signal
C0950 NUMERATOR 1 −32767 {1} 32767 CONV3
Numerator
C0951 DENOMINATO
R
1 1 {1} 32767 CONV3
Denominator
C0952
s
IN 1000 FIXEDPHI−0 ® Selection list 4 CONV3
Configuration of analog input
C0953 (C0952) g −32767 {1 rpm} 32767 CONV3
Display of analog input signal
C0955 NUMERATOR 1 −32767 {1} 32767 CONV4
Numerator
C0956 DENOMINATO
R
1 1 {1} 32767 CONV4
Denominator
C0957
s
IN 1000 FIXEDPHI−0 ® Selection list 4 CONV4
Configuration of analog input
C0958 (C0957) g −32767 {1 rpm} 32767 CONV4
Display of analog input signal
C0960 FUNCTION 1 1
2
3 Characteristic 1
Characteristic 2
Characteristic 3 CURVE1
Selection of the characteristic function
C0961 Y0 0.00 0.00 {0.01 %} 199.99 CURVE1
Interpolation point configuration
C0962 Y1 50.00 0.00 {0.01 %} 199.99 CURVE1
Interpolation point configuration
C0963 Y2 75.00 0.00 {0.01 %} 199.99 CURVE1
Configuration − grid point
C0964 Y100 100.0
0
0.00 {0.01 %} 199.99 CURVE1
Configuration − grid point
C0965 X1 50.00 0.01 {0.01 %} 99.00 CURVE1
Configuration − grid point
C0966 X2 75.00 0.01 {0.01 %} 99.00 CURVE1
Configuration − grid point
C0967
s
IN 1000 FIXED0% ® Selection list 1 CURVE1
Configuration of analog input
C0968 (C0967) g −199.99 {0.01 %} 199.99 CURVE1
Display of analog input signal
C0970
s
N−SET 1000 FIXED0% ® Selection list 1 MFAIL
Configuration of speed input signal (setpoint
path)
C0971
s
FAULT 1000 FIXED0 ® Selection list 2 MFAIL
Configuration of digital input signal
(activation of mains failure control)
C0972
s
RESET 1000 FIXED0 ® Selection list 2 MFAIL
Configuration of digital input signal (reset of
mains failure control)
C0973
s
ADAPT 1000 FIXED0% ® Selection list 1 MFAIL
Configuration of input signal for adaptation
of voltage controller P−gain
C0974
s
CONST 1000 FIXED0% ® Selection list 1 MFAIL
Configuration of input signal for adaptation
of voltage controller P−gain
C0975
s
THRESHLD 1000 FIXED0% ® Selection list 1 MFAIL
Configuration of input signal for restart
protection when the value falls below the
speed threshold
