IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1550 ARITPH4
FUNCT
1 0
1
2
3
13
14
15
21
22 OUT = IN1
OUT = IN1 + IN2
OUT = IN1 − IN2
OUT = IN1 × IN2 / 2
30
OUT = IN1 × IN2
OUT = IN1 / IN2
OUT = IN1 % IN2
OUT = IN1 + IN2 (no limit)
OUT = IN1 − IN2 (no limit)
ARITPH4
Arithmetic function selection
C1551
s
® Selection list 3 ARITPH4
Configuration of input signals
1 ARITPH4−IN1 1000 FIXED0INC
2 ARITPH4−IN2 1000 FIXED0INC
C1552 g −2147483647 {1 inc} 2147483647 ARITPH4
Display of input signals
1 (C1551/1)
2 (C1551/2)
C1555 ARITPH5
FUNCT
1 0
1
2
3
13
14
15
21
22 OUT = IN1
OUT = IN1 + IN2
OUT = IN1 − IN2
OUT = IN1 × IN2 / 2
30
OUT = IN1 × IN2
OUT = IN1 / IN2
OUT = IN1 % IN2
OUT = IN1 + IN2 (no limit)
OUT = IN1 − IN2 (no limit)
ARITPH5
Arithmetic function selection
C1556
s
® Selection list 3 ARITPH5
Configuration of input signals
1 ARITPH5−IN1 1000 FIXED0INC
2 ARITPH5−IN2 1000 FIXED0INC
C1557 g −2147483647 {1 inc} 2147483647 ARITPH5
Display of input signals
1 (C1556/1)
2 (C1556/2)
C1560 ARITPH6−FUNC
T
1 0
1
2
3
13
14
15
21
22 OUT = IN1
OUT = IN1 + IN2
OUT = IN1 − IN2
OUT = IN1 × IN2 / 2
30
OUT = IN1 × IN2
OUT = IN1 / IN2
OUT = IN1 % IN2
OUT = IN1 + IN2 (no limit)
OUT = IN1 − IN2 (no limit)
ARITPH6
Arithmetic function selection
C1561
s
1000 ® Selection list 3 ARITPH6
Configuration of input signals
1 ARITPH6−IN1 1000 FIXED0I
NC
2 ARITPH6−IN2 1000 FIXED0I
NC
C1562 g −2147483647 {1 inc} 2147483647 ARITPH6
Display of input signals
1 (C1561/1)
2 (C1561/2)
C1580
s
CONVAD1−IN 1000 FIXED0% ® Selection list 1 CONVAD1
Configuration of analog input signal
C1581 (C1580) g −32768 {1} 32767 CONVAD1
Display of analog input signal
