Lenze EVS9332xK - Manual (Page 344)

Configuration
Code table
8
8.4
l
8.4−70 EDSVS9332K EN 8.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1425
g CSEL1
Display of digital input signals
(C1424/1)
...
(C1424/5)
C1430 0.0000 {0.0001
units}
214000.0000 PSAVE1
1 1.000
0
Window for master value comparison
2 1.000
0
Window for actual value comparison
C1431 0 0
1
2 Compare MPOS and ACTPOS
Compare MPOS only
Compare ACTPOS only PSAVE1
Memory function
C1434
s
® Selection list 2 PSAVE1
Configuration of digital input signals
1 PSAVE1−ON 1000 FIEXED0 HIGH = Comparison of inputs PSAVE1−MPOS
and PSAVE1−ACTPOS with saved values and
difference output
2 PSAVE1−SAVE 1000 FIEXED0 HIGH = Acceptance of inputs PSAVE1−MPOS
and PSAVE1−ACTPOS
C1435
g PSAVE1
Display of digital input signals
1 (C1434/1)
2 (C1434/2)
C1436
s
® Selection list 3 PSAVE1
Configuration of input signals
1 PSAVE1−MPOS 1000 FIXED0INC Input for master position
2 PSAVE1−ACTPO
S
1000 FIXED0INC Input for actual position (e.g. rotor position)
C1437
g {1 inc.} PSAVE1
Display of input signals
1 (C1436/1)
2 (C1436/2)
C1440
s
® Selection list 2 SWPHD1, SWPHD2
Configuration of digital input signals
1 SWPHD1−SET 1000 FIXED0
2 SWPHD2−SET 1000 FIXED0
C1441 g SWPHD1, SWPHD2
Display of digital input signals
1 (C1440/1)
2 (C1440/2)
C1442
s
® Selection list 4 SWPHD1/SWPHD2
Configuration of input signals
1 SWPHD1−IN1 1000 FIXEDPHI−0
2 SWPHD1−IN2 1000 FIXEDPHI−0
3 SWPHD2−IN1 1000 FIXEDPHI−0
4 SWPHD2−IN2 1000 FIXEDPHI−0
C1443 g SWPHD1, SWPHD2
Display of input signals
1 (C1442/1)
... ...
4 (C1442/4)
