Configuration
Code table
8.4
l
8.4−8
EDSVS9332K EN 8.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C0108
100.0
0
−199.99
{0.01 %}
199.99 FCOD (gain AOUT)
1 FCOD
(VERST.AOUT)
2 FCOD
(VERST.AOUT)
C0109
−199.99
{0.01 %}
199.99 FCODE (Offset AOUT)
FCODE
(OFFSET)
0.00
FCODE
(OFFSET)
0.00
C0114
0
1
HIGH active
LOW active
DIGIN polarity
Terminal polarity
1 DIGIN1 POL
0
X5/E1
2 DIGIN2 POL
0
X5/E2
3 DIGIN3 POL
0
X5/E3
4 DIGIN4 POL
1
X5/E4
5 DIGIN5 POL
0
X5/E5
C0116
s
® Selection list 2 Signal configuration FD0−xx
Free digital outputs can only be evaluated
when networked with automation interfaces.
1 FDO−O0
1000 FIXED0
... ...
...
...
32 FDO −31
1000 FIXED0
C0117
s
®
® Selection list 2 DIGOUTx
Signal configuration
à
Depending on C0005
1 DIGOUT1
15000 DCTRL−TRIP
X5/A1
2 DIGOUT2
10650 CMP1−OUT
X5/A2
3 DIGOUT3
500
DCTRL−RDY
X5/A3
4 DIGOUT4
5003 MCTRL−MMAX
X5/A4
C0118
0
1
HIGH active
LOW active
DIGOUTx
Terminal polarity
1 DIGOUT1 POL
1
X5/A1
2 DIGOUT2 POL
1
X5/A2
3 DIGOUT3 POL
0
X5/A3
4 DIGOUT4 POL
0
X5/A4
C0120 OC6 LIMIT
0
0
{1 %}
120 Threshold for I
2
× t monitoring (motor).
l
0 = I
2
× t monitoring switched off
l
I
2
× t > C0120
ð Trip OC6
C0121 OH7 LIMIT
150
45
{1 °C}
150 Temperature for OH7
Threshold for motor temperature warning
C0122 OH4 LIMIT
85
45
{1 °C}
85 Temperature for OH4
Threshold for heatsink temperature warning
C0125 BAUDRATE
0
0
1
2
3
4
9600 baud
4800 baud
2400 baud
1200 baud
19200 baud
LECOM baud rate
LECOM baud rate for 2102 module
