Configuration
Code table
8
8.4
l
8.4−4 EDSVS9332K EN 8.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0027 −199.99 {0.01 %} 199.99 FCODE (gain AIN)
Freely assignable code for relative analog
signals
l Used for:
– Gain X6/1,2
– Gain X6/3,4
1 FCODE (GAIN) 100.0
0
2 FCODE (GAIN) 100.0
0
C0030 DFOUT CONST 3 0
1
2
3
4
5
6 256 inc./rev.
512 inc./rev.
1024 inc./rev.
2048 inc./rev.
4096 inc./rev.
8192 inc./rev.
16384 inc./rev. DFOUT constant
Constant for the digital frequency output in
increments per revolution
C0032 FCODE
GEARBOX
1 −32767 {1} 32767 FCODE (gearbox factor numerator)
Freely assignable code
C0033 GEARBOX
DENOM
1 1 {1} 32767 Gearbox factor denominator
C0034 MST CURRENT 0 0
1
2 −10 V ... + 10 V
+4 mA ... +20 mA
−20 mA ... +20 mA Master voltage/master current
Selection for setpoint entry
C0037 SET−VALUE
RPM
0 −16000 {1 rpm} 16000 Setpoint selection (rpm)
C0039 −199.99 {0.01 %} 199.99 NSET JOG setpoints
Fixed speeds (JOG setpoints) can be selected
for NSET using digital inputs
1 JOG SET−VALUE 100.0
0
2 JOG SET−VALUE 75.00
3 JOG SET−VALUE 50.00
4 JOG SET−VALUE 25.00
5 JOG SET−VALUE 0.00
... ... ...
14 JOG SET−VALUE 0.00
15 JOG SET−VALUE 0.00
C0040 CTRL ENABLE 1 0
1 Controller inhibited
Controller enabled Controller enable (RFR)
C0042 QSP g 1
2
QSP: Inactive
QSP: Active Quick stop
C0043 TRIP RESET 0 0
1 Trip reset
Error active Reset error
Reset of an active trip:
l Set C0043 = 0
C0045 ACT JOG g 0
1
2
...
15
Nset is active
JOG 1
JOG 2
...
JOG 15 NSET
JOG selection
C0046 NSET−N g −199.99 {0.01 %} 199.99 NSET
Main setpoint
C0049 NSET−NADD g −199.99 {0.01 %} 199.99 NSET
Additional setpoint
C0050 MCTRL−NSET2 g −100.00 {0.01 %} 100.00 MCTRL
n
set
at speed controller input
C0051 MCTRL−NACT g −30000 {1 rpm} 30000 Actual speed value
C0052 MCTRL−UMOT g 0 {1 V} 800 Motor voltage
C0053 UG−VOLTAGE g 0 {1 V} 900 DC−bus voltage
