IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1346
s
® Selection list 4 CCTRL, CCTRL2
Configuration of input signals
1 CCTRL−IN 1000 FIXEDPHI−0 Input for main setpoint
2 CCTRL−NSET2 1000 FIXEDPHI−0 Input for alternative setpoint (2nd setpoint)
3 CCTRL2−IN 1000 FIXEDPHI−0 Input for main setpoint
4 CCTRL2−NSET2 1000 FIXEDPHI−0 Input for alternative setpoint (2nd setpoint)
5 CCTRL2−TP−SPE
ED−LIM
1000 FIXEDPHI−0 Speed selection for compensating for a
detected position deviation (touch probe).
l The input can, for instance, be linked to an
RFGPH3 function block to compensate a
position deviation via a profile generator.
C1347 g CCTRL, CCTRL2
Display of input signals
1 (C1346/1)
... ...
5 (C1346/5)
C1348 1 {1} 32767 CCTRL, CCTRL2
Adaptation of the torque feedforward control
to the moment of inertia of the machine
1 100 Torque feedforward control − numerator
2 1 Torque feedforward control − denominator
C1349 1 0
1
2
3 CW rotation mode
CW/CCW rotation mode
Absolute value encoder mode
Homing mode CCTRL
Touch probe mode
C1350 0 0
1 CW rotation
CCW rotation YSET1
Actual value of direction of rotation
C1351 0 0
1 Without offset
With offset YSET1
Compression mode
C1352
s
YSET1−FACT 1000 FIXED0% ® Selection list 1 YSET1
Stretching/compression factor:
+100 % = no stretching/compression
>100 % = compression
<100 % = stretching
C1353 (C1352) g YSET1
Display of analog input signal
C1354
s
® Selection list 2 YSET1
1 YSET1−RESET 1000 FIXED0 Reset of the −OFFS input
2 YSET1−SYNCH 1000 FIXED0 Clock pulse input for synchronous switching
of the stretching/compression factor
C1355 g YSET1
Display of digital input signals
1 (C1354/1)
2 (C1354/2)
C1356
s
YSET1−OFFS 1000 FIXED0INC ® Selection list 3 YSET1
Offset value
C1357 (C1356) g {1 inc}
C1358
s
− ® Selection list 4 YSET1
Configuration of input signals
1 YSET1−IN 1000 FIXEDPHI−0
2 YSET1−IN−SYNC
H
1000 FIXEDPHI−0
