Configuration
Code table
8
8.4
l
8.4−81 EDSVS9332K EN 8.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1726 −2147483647 {1 inc} 2147483647 STORE3
Memory
1 0 Memory location 0
2 0 Memory location 1
... 0 ...
16 0 Memory location 16
C1727 0 0 {1} 15 STORE3
Initial value at STORE3−SEL−IN
C1735 0 CCTRL2
Source for touch probe catch−up speed in the
event of deviations
0 Code 1365/1 l Detected deviations are compensate as
fast as possible with the speed selected
under C1365/1.
l Value under C1365/1 = 0: No
compensation of deviations.
1 Input CCTRL2−TP−SPEED−LIM l Detected deviations are compensated
with the speed selected at
CCTRL2−TP−SPEED−LIM.
l Signal at CCTRL2−TP−SPEED−LIM = 0: No
compensation of deviations.
l The input is only active if
CCTRL2−TP−SYNC−BUSY = High.
C1740 0 PHINT5
Source for touch probe catch−up speed in the
event of deviations
0 Code 1741/1 l Detected deviations are compensated
with the speed selected under C1741/1.
l Value in C1741/1 = 0: no compensation of
deviations.
1 Input PHINT5−TP−SPEED−LIM l Detected deviations are compensated
with the speed selected at
PHINT5−TP−SPEED−LIM.
l Signal at PHINT5−TP−SPEED−LIM = 0: No
compensation of deviations.
l The input is only active if
PHINT5−TP−SYNC−BUSY = HIGH.
C1741 0.0000 {0.0001
rpm}
15000.0000 PHINT5
Maximum touch probe catch−up speed
1 10.00
00
C1799 1250 20 {1} 1250 DFOUT f
max
(kHz)
1250 corresponds to 500 kHz
C1810 g SW identification LECOM
C1811 g SW creation
