Configuration
Code table
8.4
l
8.4−49
EDSVS9332K EN 8.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C1079
0.010
{0.001 s}
130.000 RFGPH2, RFGPH3
1
1.000
RFGPH2: STOP ramp
2
1.000
RFGPH2: Acceleration ramp
3
1.000
RFGPH2: Deceleration ramp
4
1.000
RFGPH3: STOP ramp
5
1.000
RFGPH3: Acceleration ramp
6
1.000
RFGPH3: Deceleration ramp
C1080
s
® Selection list 2 LIMPHD1
Configuration of digital input signals
1 CFG:
LIMPHD1−RESE
T
1000 FIXED0
2 CFG:
LIMPHD1−NO−L
IM
1000 FIXED0
C1081
g
LIMPHD1
Display of digital input signals
1 (C1080/1)
2 (C1080/2)
C1082
s
CFG:
LIMPHD1−DFIN
1000 FIXEDPHI−0
® Selection list 4 LIMPHD1
Configuration of input signal
C1083 (C1082)
g
LIMPHD1
Display of input signal
C1084
−16000.0000
{0.0001
rpm}
16000.0000 LIMPHD1
1
1000
Upper limit of N
max.
2
1000
Lower limit of N
max.
C1085 NO−LIM−Mode
0
LIMPHD1
Code is available from software version 3.4
onwards
0
Clear overflow buffer
If LIMPHD1−NO−LIM = HIGH, the overflow
buffer is cleared. The position is lost.
1
Empty overflow buffer
If LIMPHD1−NO−LIM = HIGH, the overflow
buffer is emptied. The increments are output
at LIMPHD1−DFOUT. The position is not lost.
C1090 OUTPUT
SIGNAL
g −2147483648
{1}
2147483647 FEVAN1
Signal output
C1091 CODE
141
2
{1}
2000 FEVAN1
Selection of the target code
C1092 SUBCODE
0
0
{1}
255 FEVAN1
Selection of the target subcode
C1093 NUMERATOR
1.000
0
0.0001
{0.0001}
100000.0000 FEVAN1
Numerator
C1094 DENOMIATOR
0.000
1
0.0001
{0.0001}
100000.0000 FEVAN1
Denominator
C1095 OFFSET
0
0
{1}
1000000000 FEVAN1
Offset setting
C1096
s
IN
1000 FIXED0%
® Selection list 1 FEVAN1
Configuration of analog input signal
C1097
s
FEVAN1−LOAD
1000 FIXED0
® Selection list 2 FEVAN1
Configuration of digital input signal
C1098 (C1096)
g −32768
{1}
32767 FEVAN1
Display of analog input signal
C1099 (C1097)
g
FEVAN1
Display of digital input signal
