Configuration
Code table
8
8.4
l
8.4−40 EDSVS9332K EN 8.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0864 0
1
2 Analog signal
Digital 0−15
Low phase CAN
Configuration of process output words for
system bus (CAN)
1 TYPEOUT1.W2 0
2 TYPEOUT2.W1 0
3 TYPEOUT3.W1 0
C0865 0
1
2 Analog signal
Digital 16−31
High phase CAN
Configuration of process output words for
system bus (CAN)
1 TYPEOUT1.W3 0
2 TYPEOUT2.W2 0
3 TYPEOUT3.W2 0
C0866 g −32768.00 {0.01%} 32767.00 CAN
1 IN1.W1
2 IN1.W2
3 IN1.W3
4 IN2.W1
5 IN2.W2
6 IN2.W3
7 IN2.W4
8 IN3.W1
9 IN3.W2
10 IN3.W3
11 IN3.W4
C0867 g CAN
1 IN1.D1
2 IN2.D1
3 IN3.D1
C0868 g −199.99 {0.01%} 199.99 CAN
1 OUT1.W1
2 OUT1.W2
3 OUT1.W3
4 OUT2.W1
5 OUT2.W2
6 OUT2.W3
7 OUT2.W4
8 OUT3.W1
9 OUT3.W2
10 OUT3.W3
11 OUT3.W4
C0869
g −2147483648
{1} 2147483647 CAN
1 OUT1.D1
2 OUT2.D1
3 OUT3.D1
C0870
s
® Selection list 2 DCTRL
Configuration of digital input signals (inhibit
controller)
1 CINH1 1000 FIXED0
2 CINH2 1000 FIXED0
C0871
s
TRIP−SET 54 DIGIN4 ® Selection list 2 DCTRL
Configuration of digital input signal
C0876
s
TRIP−RES 55 DIGIN5 ® Selection list 2 DCTRL
Configuration of digital input signal
