Configuration
Code table
8
8.4
l
8.4−21 EDSVS9332K EN 8.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0470 0 {1} 255 Freely assignable code for digital signals
l The data words C0470 and C0471 are in
parallel and are identical
0 FCODE 8BIT
DIGITAL
0
1 FCODE BIT 0−7 0
2 FCODE BIT8−15 0
3 FCODE
BIT16−23
0
4 FCODE
BIT24−31
0
C0471 FCODE 32 BIT 0 0 {1} 4294967296 FCODE 32 bits digital
Freely assignable code for digital signals
l The data words C0470 and C0471 are in
parallel and are identical
C0472 FCODE
ANALOG
−199.99 {0.01 %} 199.99 Freely assignable code for relative analog
signals
1 0.00
2 0.00
3 100.0
0
6 100.0
0
... ...
19 0.00
20 0.00
C0473 FCODE ABS −32767 {1} 32767 FCODE
Freely assignable code for absolute analog
signals
1 1
2 1
3 0
... ...
9 0
10 0
C0474 FCODE PH −2147483647 {1} 2147483647 FCODE
Freely assignable code for phase signals
1 rev = 65536 inc
1 0
... ...
10 0
C0475 FCODE PHD −16000 {1 rpm} 16000 FCODE
Freely assignable code for speed
signals/digital frequency signals
1 0
2 0
3 0
4 0
5 0
C0490
s
FEEDBACK POS 0 Position feedback system
Feedback system for the position controller
0 Resolver at X7 The feedback system can be merged with the
settings of C0495 = 0, 1, 2, 3, 4.
1 Encoder TTL at X8 The selection also sets C0495 to the same
value.
2 Sin encoder at X8
3 Absolute value encoder ST at X8
4 Absolute value encoder MT at X8
