Configuration
Code table
8
8.4
l
8.4−65 EDSVS9332K EN 8.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1359
g YSET1
Display of input signals
1 (C1358/1)
2 (C1358/2)
C1360
s
® Selection list 3 VTPOSC
Configuration of input signals
1 VTPOSC−IN1 1000 FIXED0INC
2 VTPOSC−IN2 1000 FIXED0INC
3 VTPOSC−IN3 1000 FIXED0INC
4 VTPOSC−IN4 1000 FIXED0INC
5 VTPOSC−IN5 1000 FIXED0INC
6 VTPOSC−IN6 1000 FIXED0INC
7 VTPOSC−IN7 1000 FIXED0INC
8 VTPOSC−IN8 1000 FIXED0INC
9 VTPOSC−IN9 1000 FIXED0INC
10 VTPOSC−IN10 1000 FIXED0INC
C1361 g VTPOSC
Display of input signals
1 (C1360/1)
... ...
10 (C1360/10)
C1362
s
1000 ® Selection list 4 ADDPHD1
Configuration of input signals
1 ADDPHD1−DFI
N1
FIXEDPHI−0 Addition input
2 ADDPHD1−DFI
N2
FIXEDPHI−0 Addition input
3 ADDPHD1−DFI
N3
FIXEDPHI−0 Subtraction input
C1363 g ADDPHD1
Display of input signals
1 (C1362/1)
2 (C1362/2)
3 (C1362/3)
C1364 0 YSET1
OFFSET−RESET mode
0 Y−Offset reset Offset is internally stored with
YSET1−RESET = HIGH
1 y−Offset disable Offset is internally set to "0" with
YSET1−RESET = HIGH
C1365 0.0000 {0.0001
rpm}
15000.0000 CCTRL, CCTRL2
Maximum touch probe catch−up speed
Function only possible with C1366 = 0
(without catch−up limitation)
1 100.0
000
C1366 0 CCTRL
Selection of catch−up speed limitation
0 Without catch−up limitation
1 With catch−up limitation
