Configuration
Code table
8.4
l
8.4−22
EDSVS9332K EN 8.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C0495
s
FEEDBACK N
0
Speed feedback system
Feedback system for the speed controller
0
Resolver at X7
The feedback system can be merged with the
settings of C0490 = 0, 1, 2, 3, 4.
l
A setting of C0495 = 0 sets the rotor
displacement angle in C0058 to −90°
1
Encoder TTL at X8
The selection also sets C0490 to the same
value.
2
Sin/cos encoder at X8
3
Hiperface single−turn absolute value
encoder at X8
4
Hiperface multi−turn absolute value
encoder at X8
C0497 NACT−FILTER
2.0
0.0
{0.1 ms}
50.0 Nact filter time constant
Time constant for actual speed value
C0497 = 0 ms: Switched off
C0499
0
Mode of profile data access protection
0
Read/write protection
1
Only read protection
2
Only write protection
C0500 CAM CHECK
ACTUAL CURVE
0
CAM check of actual profile
0
No CAM check
1
CAM check of all data
2
CAM check, X axis only
3
CAM check, Y axis only
C0503
0
{1}
65535 Password
The allocation of passwords prevents
unauthorised access to profile data and
parameter set
1
0
PIN − profile data
2
0
Master PIN − profile data
C0506
g
1
Version
2
Data field length
