Configuration
Code table
8
8.4
l
8.4−6 EDSVS9332K EN 8.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0081
s
MOT POWER à 0.01 {0.01 kW} 150.00 Rated motor power acc. to nameplate
à Depending on C0086
l Change of C0086 resets value to the
assigned default setting
l Change of C0081 sets C0086 = 0
C0084
s
MOT RS à 0.00 {0.01 W} 150.00 Motor stator resistance
à Depending on C0086
l Change of C0086 resets value to the
assigned default setting
C0085
s
MOT LS à 0.00 {0.01 mH} 655.35 Motor leakage inductance
à Depending on C0086
l Change of C0086 resets value to the
assigned default setting
C0086
s
MOT TYPE à See motor selection list Motor type selection
à Depending on the controller used
l Change of C0086 resets C0006, C0022,
C0070, C0071, C0075, C0076, C0081,
C0084, C0085, C0087, C0088, C0089,
C0090, C0091 to the assigned default
setting
Controller Lenze
setting Assigned motor
type Lenze motor type
EVS9321 110 MDSKS56−23−150 MDSKSXX056−23, f
r
: 150Hz
EVS9322 111 MDSKS56−33−150 MDSKSXX056−33, f
r
: 150Hz
EVS9323 112 MDSKS71−13−150 MDSKSXX071−13, f
r
: 150Hz
EVS9324 116 MDSKS71−33−150 MDSKSXX071−33, f
r
: 150Hz
EVS9325 15 MDFKA80−120 MDFKAXX080−22, f
r
: 120Hz
EVS9326 19 MDFKA90−120 MDFKAXX090−22, f
r
: 120Hz
EVS9327 23 MDFKA100−120 MDFKAXX100−22, f
r
: 120Hz
EVS9328 27 MDFKA112−120 MDFKAXX112−22, f
r
: 120Hz
EVS9329 225 30kW−ASM−50 —
EVS9330 227 45kW−ASM−50 —
EVS9331 228 55kW−ASM−50 —
EVS9332 229 75kW−ASM−50 —
C0087
s
MOT SPEED à 300 {1 rpm} 16000 Rated motor speed
à Depending on C0086
l Change of C0086 resets value to the
assigned default setting
C0088
s
MOT CURRENT à 0.2 {0.1 A} 500.0 Rated motor current
à Depending on C0086
l Change of C0086 resets value to the
assigned default setting
C0089
s
MOT
FREQUENCY à 10 {1 Hz} 1000 Rated motor frequency
C0090
s
MOT VOLTAGE à 50 {1 V} 500 Rated motor voltage
à Depending on C0086
l Change of C0086 resets value to the
assigned default setting
C0091
s
MOT COS PHI à 0.50 {0.01} 1.00 Motor cos
j
à Depending on C0086
l Change of C0086 resets value to the
assigned default setting
C0093 DRIVE IDENT g 0
1
93xx
Defective power section
No power section
93xx Controller identification
93xx: servo cam profiler type
