Configuration
Code table
8.4
l
8.4−61
EDSVS9332K EN 8.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C1324
s
® Selection list 3 CDATA, CURVEC1
Configuration of input signals
1 CDATA−X−STAR
T
1000 FIXED0INC
2 CDATA−XIN
1000 FIXED0INC
Input for master value position if C1332 = 1
3 CDATA−XOFFS
1000 FIXED0INC
Input for offset in X direction (only if
C1332 = 0)
4 CDATA−TP−POS
19616 FCODE 1476/16
TP position of the master value
5 CURVEC1−IN
1000 FIXED0INC
Phase input
6 CADTA−YIN
1000 FIXED0INC
Y position input signal for the TEACH function
7 CDATA−OFFS−XI
N
1000 FIXED0INC
Offset on the input signal at CDATA−XIN for
C1338 = 1 or C1338 = 2
C1325
g
{1 inc}
CDATA, CURVEC1
Display of input signals
1 (C1324/1)
... ...
7 (C1324/7)
C1326
s
® Selection list 3 CDATA
Configuration of input signals
1 CDATA−DFIN
1000 FIXEDPHI−0
Input for digital frequency at C1332 = 0
2 CDATA−TP−SPEE
D−LIM
1000 FIXEDPHI−0
Speed selection for a touch probe correction
l
The input can, for instance, be linked to an
RFGPH2 function block to compensate a
position deviation via a profile generator.
C1327
g
CDATA
Display of input signals
1 (C1326/1)
2 (C1326/2)
C1329
g
CDATA
Display of X values in [m/units]
1
X axis position CDATA−X−ACT
2
X integrator position CDATA−XPOS
3
Distance between two marks
4
Offset to mark
C1330
g
CDATA
Display of X values in [s/units]
1
Profile position CDATA−YOUT
2
Profile position CDATA−YOUT−CYCLE
C1331
100
0
{1 rpm}
15000 CDATA
Maximum TP catch−up speed. Only valid for:
l
C1335 = 1
l
C1335 = 2
C1332
0
CDATA
Selection of master value
0
Master value from CDATA−DFIN
1
Master value from CDATA−XIN
2
Master value from CDATA−XPOS
C1333
g
{1 inc}
CDATA
Actual X position
C1334
g
CDATA
Actual Y position
C1335
0
0
1
2
Without catch−up limitation
With catch−up limitation
Cross cutter
CDATA
Effect on the catch−up speed during master
axis synchronisation via touch probe
