Configuration
Code table
8.4
l
8.4−13
EDSVS9332K EN 8.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C0202 INTERNAL IO
g 0
{0.001}
100.000 Internal identification
C0203 KOMM.−NO.
g x / xxxx / xxxxx
Commission number
C0204 SERIAL−NO.
g 0
{1}
65535 Serial number
C0206 PRODUCT
DATE
g
Production date of the device
C0207 DL INFO 1
g
Download info 1
C0208 DL INFO 2
g
Download info 2
C0209 DL INFO 3
g
Download info 3
C0220 NSET TIR ADD
0.000 0.000
{0.001 s}
999.900 NSET
Acceleration time T
ir
of the additional
setpoint for NSET
(refers to speed change 0...n
max.
)
C0221 NSET TIF ADD
0.000 0.000
{0.001 s}
999.900 NSET
Deceleration time T
if
of the additional
setpoint for NSET
(refers to speed change 0...n
max.
)
C0222 PCTRL1 VP
1.0
0.1
{0.1}
500.0 PCTRL1
V
p
gain
C0223 PCTRL1 TN
400
20
{1 ms}
99999 PCTRL1
T
n
I component
99999 ms: Switched off
C0224 PCTRL1 KD
0.0
0.0
{0.1}
5.0 PCTRL1
K
d
differential component
C0241 CMP RFG−I = O
1.00
0.00
{0.01 %}
100.00 NSET
Threshold of ramp function generator for
main setpoint input = output, (100 % = n
max
)
C0244 BRK M SET
0
−100.00
{1.00 %}
100.00 BRK1
Holding torque of the DC injection brake
100 % = value of C0057
C0250 FCODE 1BIT
0
0
1
Lower limit
Upper limit
FCODE 1bit digital
C0252 ANGLE OFFSET
0
−245760000
{1 inc}
245760000 DFSET
Phase offset, constant angular offset for
digital frequency configurations
l
1 rev = 65536 inc
C0253 ANGLE N−TRIM
®
−32767
{1 inc}
32767 DFSET
Speed−dependent phase trimming
à
Depending on C0005, C0025, C0490
l
Change of C0005, C0025, or C0490 resets
C0253 to the default setting
l
1 rev = 65536 inc
l
C0253 is reached at 15000 rpm
C0254 VP ANGLE CTRL
0.400
0
0.0000
{0.0001}
3.9999 MCTRL
V
p
phase controller
C0255 THRESHOLD
P03
32768
0
10
{1 inc}
1800000000 Following error limit P03
l
1 rev = 65536 inc
l
Following error > C0255 triggers fault
"P03"
C0260 MPOT1 HIGH
100.0
0
−199.99
{0.01 %}
199.99 MPOT1
Upper limit (condition: C0260 > C0261)
C0261 MPOT1 LOW
−100.0 −199.99
{0.01 %}
199.99 MPOT1
Lower limit (condition: C0261 < C0260)
C0262 MPOT1 TIR
10.0
0.1
{0.1 s}
6000.0 MPOT1
Acceleration time
(referring to change 0 ... 100 %)
