Troubleshooting and fault elimination
Troubleshooting
Fault analysis via LECOM status words (C0150/C0155)
9.2
9.2.3
l
9.2−3
EDSVS9332K EN 8.0−07/2013
9.2.3
Fault analysis via LECOM status words (C0150/C0155)
The LECOM status words (C0150/C0155) are coded as follows:
Code
Possible settings
IMPORTANT
No.
Designation
Lenze/
{Appl.}
Selection
C0150 Status word
0
Device status word for networking
via automation interface (AIF)
Read only
0
{1}
65535 Controller evaluates information as
16 bits (binary−coded)
Bit 0
Not assigned
Bit 1
Pulse inhibit (IMP)
Bit2
Not assigned
Bit3
Not assigned
Bit4
Not assigned
Bit5
Not assigned
Bit 6
n = 0
Bit 7
Controller inhibit (CINH)
Bit 8
Device status bit 1
Bit 9
Device status bit 2
Bit10
Device status bit 3
Bit11
Device status bit 4
Bit12
Warning
Bit13
Message
Bit14
Not assigned
Bit15
Not assigned
C0155 Status word 2
0
Status word 2 (advanced status
word)
Display only
0
{1}
65535 Controller interprets information as
16 bit (binary coded)
Bit 0
Active fault
Bit 1
M
max
reached
Bit 2
I
max
reached
Bit 3
Pulse inhibit(IMP)
Bit 4
Ready for operation (RDY)
Bit 5
Controller inhibit (CINH)
Bit 6
TRIP active
Bit 7
Initialisation
Bit 8
Motor direction of rotation (Cw/CCw)
Bit 9
Not assigned
Bit 10
Not assigned
Bit 11
Not assigned
Bit 12
Not assigned
Bit 13
Not assigned
Bit 14
Not assigned
Bit 15
Not assigned
