Parameter setting
Parameter setting with the XT EMZ9371BC keypad
Changing and saving parameters
7
7.2
7.2.4
l
7.2−4 EDSVS9332K EN 8.0−07/2013
)
Note!
Shortcuts with
T:
Press and hold
T, then press the second key in addition.
Key Function
Menu level Code level Parameter level Operating level
V
Change to the
parameter level Change to the
operating level Change to the code
level
T V
Go to the
"Short setup"
menu and load
predefined
configurations
1)
Accept parameters
when SHPRG
p or
SHPRG is displayed
z
y
Change between
menu items Change of code
number Change of digit via
cursor
T z
T y
Quick change
between menu
items
Quick change of
code number Quick change of
digit via cursor
Z
Change between main menu, submenu
and code level
Cursor to the right
Y Cursor to the left
U Deactivate the function of the key S, the LED in the key goes off
S Inhibit the controller, the LED in the key is lit.
Reset fault
(TRIP−Reset): 1. Remove the cause of malfunction
2. Press
S
3. Press U
1) Only active for operation with standard devices of the 8200 vector or 8200 motec series
7.2.4 Changing and saving parameters
)
Note!
Your settings have an effect on the current parameters in the
main memory. You must save your settings in a parameter set so
that they are not lost when the mains are connected.
If you only need one parameter set, save your settings as
parameter set 1, since parameter set 1 is loaded automatically
after mains connection.
Step Key
sequence Action
1. Select the menu z y Z Y Use the arrow keys to select the desired
menu
2. Change to the code level Z Display of the first code in the menu
3. Select code or subcode y z Display of the current parameter value
4. Change to the parameter level V
5. When SHPRG is displayed,
inhibit the controller S 1) The drive coasts
6. Change parameter
A Z Y Move cursor below the digit to be changed
B y z Change of digit
