Wiring of the standard device
Control terminals
Terminal assignment
5
5.8
5.8.6
l
5.8−9 EDSVS9332K EN 8.0−07/2013
5.8.6 Terminal assignment
Terminal Jumper strip
X3
Jumper setting Possible levels
X6/1,
X6/2
1
3
5
2
4
6 1−2 1) −10 V ... +10 V 1)
3−4 −10 V ... +10 V
5−6 −20 mA ... +20 mA
1) Lenze setting (delivery state)
Terminal Description Function Level / state
X11/K32
X11/K31 Safety relay K
SR
1st
disconnecting
path
Pulse inhibit feedback Open contact: pulse
inhibit is inactive
(operation)
Closed contact:
pulse inhibit is active
X11/33 – coil of safety relay K
SR
Coil is not carrying
any current: pulse
inhibit is active
X11/34 + coil of safety relay K
SR
Coil is carrying
current: pulse inhibit
is inactive
(operation)
X5/28 Controller
inhibit
(DCTRL−CINH)
2nd
disconnecting
path Controller enable/inhibit LOW: Controller
inhibited
HIGH: Controller
enabled
X5/ST1
X5/ST2 STATE−BUS
Terminal Description Function Level
X5/E1 Digital inputs Deactivate quick stop/ CW rotation HIGH
X5/E2 Deactivate quick stop/ CCW rotation HIGH
X5/E3 Activate fixed frequency 1 HIGH
X5/E4 Set error message (TRIP set) LOW
X5/E5 Reset error message (TRIP reset) LOW−HIGH edge
X5/A1 Digital outputs Error message available LOW
X5/A2 Switching threshold Q
MIN
: actual speed
< setpoint speed in C0017
LOW
X5/A3 Ready for operation (DCTRL−RDY) HIGH
X5/A4 Maximum current reached (DCTRL−IMAX) HIGH
X6/1,
X6/2 Analog inputs Main speed setpoint −10 V ... +10 V
X6/3,
X6/4 Additional speed setpoint −10 V ... +10 V
X6/62 Analog outputs Actual speed value −10 V ... +10 V
X6/63 Torque setpoint −10 V ... +10 V
Analog input configuration
Non−configurable control
terminals
Configurable control
terminals (Lenze setting)
