• If you suspect the results are incorrect, then adjust the appropriate look-ahead setting one-tenth (.1)
second per trial. When making changes to the look-ahead settings, make sure to adjust these settings
only one-tenth (.1) second per trial. Larger adjustments can cause unintentional large changes in the
AutoSwath’s performance. When adjusting the look-ahead numbers from the suggested settings, it is
recommended that you observe multiple trials to confirm the operations’ accuracy.
• If you encounter overplanting or underplanting problems, see “Fixing Overplanting and Underplanting in
AutoSwath” on page 72.
H
YDRAULIC
S
EED
R
ATE
C
ONTROL
The Hydraulic Seed Control Module is a SeedCommand™ product that allows users to control up to
three hydraulic motor drives via the display. Configure the Hydraulic Seed Rate Control module in the
following order.
1. Configure Hydraulic Seed Rate Control module
See “Hydraulic Seed Rate Control Configuration” on page 84 .
2. Enter Controller Settings
Included the Max Meter Speed, Gear Ratio and Minimum Allowable Ground Speed. See “Controller Settings
for Hydraulic Seed Rate Motor Drives” on page 85 .
3. Prime the Hydraulic Seed Meter
This fills the seed meter with seed, and thus allows you to avoid skips in your field. See “Priming Seed Rate
Meters” on page 94
4.
- a. Enter Meter Calibration Number. This number, representing seeds per revolution, is set according
to the number of seed dropped per one revolution of the seed meter. For more information,
“Calibrating Seed Rate Meters” on page 94 .
- b. Perform a Seed Meter Calibration (not always required). A new calibration should be performed if
your as-applied seed rate does not match the actual population planted. For more information,
“Calibrating Seed Rate Meters” on page 94 .
H
YDRAULIC
S
EED
R
ATE
C
ONTROL
C
ONFIGURATION
Press the Planting button at the Setup Screen and go to the Planting Configuration Tab.
1. Create or add a vehicle
Follow the on-screen wizard to set up a vehicle.
2. Add Implement
After you have completed the vehicle configuration, the Implement Attachment Wizard appears. Add a new
implement, and select the implement attachment method.
3. Select Implement
Using the drop-down box, select the implement you would like to use in this configuration. If there are no
implements in the list, press the New button.
4. Select Operation Type
Select the Rate Logging/Control operation type. Press the blue right-arrow button to continue.
