137
A
PPLICATION
Note: Individual boom widths must equal the total.
This step is skipped if you are using a Tractor, ATV, or Pickup Truck.
-d. Enter a Vehicle Name. The vehicle’s default name is the Make and Model you entered in step 1b. If
necessary, edit that name by pressing the keyboard button and typing the preferred name.
Press the checkmark box.
3. Select Implement
Select the desired implement from the drop down list; then press the blue right-arrow button and proceed
to step 3. If your implement is not listed, press New and proceed to step 2b.
Note: This step does not apply if you have a self-propelled sprayer. Instead, proceed to step 4.
-a. Use the drop-down menu to select the correct Implement Attachment Method and press the blue
right-arrow button to continue.
-b. Use the numeric keypad to enter the appropriate swath width and press the blue right-arrow button to
continue.
-c. Use the up and down arrow buttons to enter in the number of boom sections. Press the blue right-
arrow button to continue.
-d. The section numbers and swath widths of the sections are displayed in the next screen. If necessary,
adjust the boom widths by pressing on the section number and use the numeric keypad to enter
the actual measured width of the boom section. Repeat the process for every boom section until
each is correct. Press the blue right-arrow button when complete.
Note: Individual boom widths must equal the total.
-e. Press the numeric keypad to enter the distance from hitch to application point. When complete, press
the blue right-arrow button.
Note: The distance settings must be measured accurately for the AutoSwath™ feature to work properly.
-f. Enter an implement name by using the keyboard button to type in the preferred name. When
complete, press the checkmark box.
4. Select Operating Mode
The Operating Configuration Wizard reappears, and you are asked to select an Operating Mode. Use the
drop-down menu to select Rate Logging/Control and press the blue right-arrow button to continue.
5. Select Controller Configuration
Select the desired DirectCommand controller configuration from the list and continue to next step, or press
New if the desired controller is not listed.
