*Adjust this number to fit your particular configuration. Refer to the Application section in the InSight
User Manual for more information on adjusting this response threshold.

**If you are using a PWM control valve, some adjustment may need to be made to achieve optimal pump
response to the PWM gain value. Increase the Gain value to make the system more responsive;
decrease the Gain value to smooth the system response.

L

IQUID

S

ERVO

S

ETTINGS

D

ESCRIPTION

• Valve Response 1
Default Value: 100%

Determines the speed of the servo valve when product control error exceeds the Response Threshold
setting.

Decreasing the value will cause the servo valve to run slower.

• Valve Response 2
Default Value: 24%

Determines the speed of the servo valve when product control error is less than the Response Threshold
setting.

Decreasing the value will cause the servo valve to run slower.

• Allowable Error
Default Value: 2%

Determines the percent of error that is allowed prior to the product control system making any flow rate
corrections.

2% - 3% is the normal dead band setting range.

- Too low of a setting value can cause the product control system to continually hunt for the target

application rate.

- Too high of a setting will cause excessive product application error.

• Response Threshold
Default Value: 3

Determines where the control system switches between using Valve Response 1 or Valve Response 2
speed setting.

Leaving all other valve control settings at the default value and making a small adjustment to this setting is
usually all that is required to fine tune system performance.

- Decreasing this value will have the overall effect of speeding up servo valve response.

- Increasing this value will have the overall effect of slowing servo valve response.

Walker

Pump Servo

2%

100%

24%

3

Control Valve Settings for Self-Propelled Sprayers (Continued)

Flow Control

Valve or

Sprayer Model

(and year if

applicable)

Control System

PWM

Frequen

cy

Typical

Gain

Range

Zero

Offset

Allowabl

e Error

Valve

Respon

se

1

Valve

Respon

se

2

Respon

se

Thresho

ld
