68
4. The Operating Configuration Wizard appears, as shown.
From here, follow the Wizard’s instructions to create a
configuration that includes Vehicle, Implement, and Controller
settings
Note: From the Configuration Tab, you can also:
• Press the on-screen keyboard to edit or rename existing configurations.
• Press the Wrench button to access Configuration Settings. For more information see “Configuration
Settings” on page 68.
• Press the Remove button to remove a configuration. Caution: When deleting a configuration all data logged
with that configuration will be deleted.
C
ONFIGURATION
S
ETTINGS
By highlighting a configuration and pressing the Wrench button on the Configuration Tab, you
can summon the Configuration Settings screen, where you can edit Configuration Settings,
Speed Input Settings, Auxiliary Input Settings and AutoSwath Settings.
Press to display and edit planting/seeding settings specific to a
vehicle, implement and controller combination. For more
information, see
“Configuration Settings: Equipment Configuration”
on page 69.
• Speed Input
Press to select speed input device. For more information, see
“Speed Input Settings” on page 69.
• Aux Input
Press to display Auxiliary Input settings. For more information, see
“Auxiliary Input Settings (Switch Mapping)” on page 70.
• AutoSwath
Press to display and edit automatic swath control settings. For more information, see
“AutoSwath” on
page 71.
Note: You must have an unlock code to activate the AutoSwath feature. If you have been using AutoSwath
with the DirectCommand™ system, the feature is already activated and ready to use. If you have not unlocked
the AutoSwath feature yet, the code can be purchased through your local dealer.
