33
GPS
- If the Fast Update Rate is ON, then your receiver is capable of outputting an update rate faster than 1
Hz per second.
- If the Fast Update Rate is OFF, then currently your receiver is only capable of an update rate of 1 Hz
per second. Contact Technical Support to see if your receiver can be upgraded to a faster update rate.
Note: The settings shown on this GPS Information screen varies, depending upon your model of GPS
receiver.
Fast Update Rate and Everest Multipath are only available with TSIP receivers.
O
N
T
RAC
2 I
NFORMATION
Users of the OnTrac2 guidance system can also view the
OnTrac2 Information screen below, in addition to the GPS
Information screens discussed previously.
• OnTrac2 Vehicle
Displays active vehicle profile.
• ESC Firmware Version and ECU Firmware Version
Displays current firmware versions for OnTrac2.
• Steering Status
Displays either Good or Bad. If the MDU does not have power, it will display a message stating MDU Power
Error.
P
ARA
D
YME
I
NFORMATION
Users of the ParaDyme guidance system can also view the
ParaDyme Information screen (shown at the left) in addition to
the GPS Information screens discussed previously.
• Firmware Version
Displays ParaDyme firmware version.
• Serial Number
Displays ParaDyme serial number.
• Active Vehicle
Displays current steering profile.
• Steering Status
Displays either Good or lists system errors.
NTRIP I
NFORMATION
Users of the NTRIP guidance system can also view the NTRIP
Information screen below, in addition to the GPS Information
screens discussed previously
• Connect
Connects the display to the NTRIP correction source.
• NTRIP Stream
Network mount point.
