6. Select Controller
Select an existing controller from the Controller List. If a new Controller needs to be created, press the New
button to start the controller wizard.
7. Select Device and Direct Type
Use the drop-down menu to select DirectCommand for the Device and Liquid Product Control for the Direct
Type. Press the blue right arrow button to continue.
8. Enter the Flow Meter Calibration Number
Enter the pulses/unit calibration number for the product flow meter. Press the blue right-arrow button to
continue.
9. Enter Suggested Controller Name
A default name of DirectLiquid appears. Use the default name or enter a new name for the DirectCommand
Liquid Configuration. Press the green check mark button to continue the configuration process.
10. Select Container
The Equipment Configuration Wizard reappears. Use the drop-down list to select an existing container, and
press the blue right-arrow button to continue. Otherwise, press the Add button to add a container.
Note: If you selected an existing container, skip ahead to Step 13.
11. Enter Container Capacity and Units
The Container Setup Wizard appears. Enter the container Capacity using the on-screen keypad. Select the
Units used to represent the Capacity of the container. Press the blue right-arrow button to continue.
12. Enter Container Name and Location
Use the on-screen keyboard to assign a name to the Container. Press the green check mark button to
complete the Container setup process and return to the Operating Configuration Wizard.
13. Enter Suggested Name for Configuration
Use the keyboard button to edit the suggested configuration name. Press the green check mark button and
continue the procedure.
14. Add Equipment for Dual Product Application
The Operating Configuration Wizard reappears. Highlight your first equipment configuration and begin
adding a Direct Injection configuration by pressing the Add Injection button, located to the left of the list.
15. Select Injection Controller
Press the Add button to create a new injection controller.
16. Enter Controller Name
The on-screen keyboard appears. Use this keyboard to enter a controller name. Press the green check
mark button and return to the Equipment Configuration Wizard
17. Select Container
Press the Add button to enter a new container. Press the blue right-arrow button to continue.
18. Enter Container Capacity and Units
In the Container Setup Wizard, enter the container Capacity using the on-screen keypad. Use the drop-
down menu underneath to select a Container Location. Select the Units used to represent the Capacity of
the container. Press the blue right-arrow button to continue.
19. Enter Container Name and Location
Use the on-screen keyboard to assign a name to the Container. Press the green check mark button to
complete the Container setup process and return to the Operating Configuration Wizard.
