127
A
PPLICATION
• Zero RPM Offset
Default Value: 30
This setting represents the maximum duty cycle that is sent to the control valve without producing any
hydraulic flow from the PWM valve. Using too high of a Zero RPM Offset value can cause the product
control system to not properly shut off. See PWM valve manufacturer information for recommended
settings.
• Allowable Error
Default Value: 2% (2% - 3% is the normal dead band setting range.)
- Too low of a setting value can cause the product control system to continually hunt for the target
application rate.
- Too high of a setting will cause excessive product application error.
• Auto Control Check Box
Default is unchecked
Checking the Auto Control check box allows you to control the spinner speed.
D
ICKEY
J
OHN
NH3 C
ONVERSIONS
Conversion Formulas
Note: The flow sensor constant is tagged on the Dickey-john flow meter. The density setting comes from a
chart in the Dickey-john documentation and is not provided in this manual.
A
PPLICATION
: D
IRECT
C
OMMAND
™ M
ACHINE
-
S
PECIFIC
S
ETUP
DirectCommand™ provides variable rate application control over liquid, dry or anhydrous application.
You apply product where it will benefit your crop most and apply less where it won’t. This subsection
describes the following DirectCommand features:
• Map Screen functions
beginning on
“Map Screen: Zoom to Extent” on page 128 .
Conversion Formula
Formula for flow meter calibration for Dickey John reading pounds of anhydrous
Flow sensor constant (pulses/in
3
) X 1728 (in
3
/ft
3
) X 5.11 (lbs. of anhydrous/gal)
Density (lbs. of anhydrous/ft3)
Formula for flow meter calibration for Dickey John reading pounds of Nitrogen
Flow sensor constant (pulses/in
3
) X 1728 (in
3
/ft
3
) X 4.22 (lbs of N/gal)
Density (lbs. of N/ft
3
)
