To view detailed system diagrams for various machine configurations, go to the Support Tab of the Ag
Leader Web site, which can be referenced via the following URL:

http://www.agleader.com/support.php?Page=manuals/diagrams

Note: To view and/or print the System diagrams, you will need the Adobe Acrobat or Adobe Reader .pdf file
format. The Adobe Reader software comes pre-installed on most personal computers. If Adobe Reader is not
installed on your computer the program is available for download at no charge. A link to the Adobe download

site is located at the Ag Leader Web site.

ILE

ORMATS

RESCRIPTION

ILE

YPES

• .irx
The *.irx file supports multiple product prescription recommendations in a single file.

• .shp, .shx, .dbf (shape file group)
What is commonly called a shape file is actually a collection of three different files. All three of the files are
required and must be present on the external storage card for the system to use shape file groups for
variable rate product application. A single "shape file" can contain recommendation rates for multiple
products.

OUNDARY AND

UIDELINE

ILE

YPES

• .iby
Boundary file format. Boundary files are created via the Map Options icon on the Map Screen, or imported
to the system from the Grower Management Tab.

YSTEM

ILE

YPES

• .ibk
Backup files are written to the external storage card by pressing the Create Backup File button at the
Console Screen’s Memory Tab.

• .ilf
Log files are created with the Copy to Card button at the Console Screen’s Advanced Tab.

• .fw2
Firmware upgrade file for the display and control modules. Install firmware updates from the external
storage card by pressing the Upgrade button on the Console Screen’s Memory Tab.
