172
3. Follow the Wizard’s instructions
The Wizard’s instructions will guide you through the necessary
steps to create a configuration that includes Combine, Header and
Crops settings.
Note: From the Configuration Tab, you can also:
• Press the on-screen keyboard to edit or rename existing configurations.
• Press the Wrench button to access Configuration Settings (see following page).
• Press the Remove button to remove a configuration. Caution: When deleting a configuration all harvest data
logged with that configuration will be deleted.
C
ONFIGURATION
S
ETTINGS
By highlighting a configuration and pressing the
Wrench button on the Configuration Tab, you can
summon the Configuration Settings screen, where
you can choose primary and backup speed source, Calibrate
Distance, or adjust AutoSwath settings.
Primary and Backup Speed Source
The ground speed source can be changed in the Primary and Backup drop-down menus in the
Configuration Settings Screen.
• If any source other than GPS is selected, the primary speed source is the only setting that you will need
to set.
• If you select GPS as the primary speed source, then you will also need to select a secondary (backup)
source in case of GPS signal loss.
Calibrate Distance
If you are not using GPS for ground speed, then after you have created a configuration you must
calibrate the ground speed input for accurate speed and area calculations. If you are using GPS, you still
must calibrate distance in the event of GPS loss.
1. Open Configuration Settings screen.
On the Configuration Tab, press on the configuration
name to highlight it, then press the Wrench Button,
and the Configuration Settings screen appears, as shown.
