See also:
“Viewing Remote Copy Links” (page 240)
“Viewing System Alerts” (page 287)
Viewing Remote Copy Groups
A Remote Copy group is a group of virtual volumes on the same storage server that are logically
related, and on which Remote Copy operations are performed.
To view Remote Copy groups:
1.
In the Manager Pane, select Remote Copy.
2.
In the Management Tree, select Groups under the Remote Copy Configuration node for the
Remote Copy configuration you want to view.
Information about Remote Copy groups appears on three panes in the Management Window:
•
The left pane displays a graphical representation of the selected Remote Copy configuration.
The image includes the type of Remote Copy relationship (RCIP or RCFC) between the servers
in the Remote Copy configuration, the direction of replication (indicated with an arrow)
between the servers, the synchronization and Remote Copy status of the Remote Copy groups,
and the number of volumes being replicated. This image is updated for the Remote Copy
group selected from the upper right pane.
•
The upper right pane displays a table of the Remote Copy groups in the selected Remote Copy
configuration.
•
The lower right pane displays a table of the virtual volume(s) belonging to the selected Remote
Copy group from the upper right pane. The table can be filtered to display information about
virtual volume Pairs, the Source virtual volume, or the Backup virtual volume.
NOTE:
You can view only synchronous Remote Copy groups or asynchronous periodic Remote
Copy groups by selecting either Synchronous or Periodic under the Groups node in the Management
Tree.
See also:
“Viewing Configured Remote Copy Systems” (page 236)
Viewing Remote Copy Information 239
