4-2
IM 04L31A01-17E
4.2 Configuring the Modbus Protocol
Explanation
Selecting the Baud Rate
Select the baud rate from the following:
1200, 2400, 4800, 9600, 19200, and 38400
Selecting the Parity Check
Select the parity check from the following:
Odd, Even, and None
Selecting the Slave Address (valid when operating as a Modbus slave)
Select the address from the following values.
1 to 32
Selecting the Modbus Protocol
Select [Modbus] if you wish to communicate using the Modbus slave protocol.
Select [Modbus-M] if you wish to communicate using the Modbus master protocol.
Selecting the Communication Type Used to Output the Data in the Internal Memory
and Files on the External Storage Medium
Select [Ethernet] when using output commands (ME, MI, and MO commands) to
output the data in the internal memory of the CX (display, event, TLOG, manual
sample, and report data) and the files on the external storage medium.
[Serial], even if selected, is invalid.
Saving the settings
To activate the settings that have been changed in the basic setting mode, the
settings must be saved. Otherwise, the settings that existed before the change are
activated.
Note
The data length and handshaking settings are invalid in the configuration of the Modbus protocol.
