6-43
IM 04L31A01-17E
6
Command
For hourly, daily, hourly + daily and daily +
monthly reports
Syntax
RO p1,p2,p3
p1: Report type (HOUR, DAY, HOUR+DAY,
DAY+MONTH)
p2: Date of creation (dd fixed form)
ddDay (01 to 28)
p3: Hour of creation (hh fixed form)
hhHour (00 to 23)
Query
RO?
Example
Create a daily report at 9 o’clock everyday
(parameter p2 (“05” in this example) is invalid in
this case).
RODAY,05,09
Description This command can be used on models with the
computation function option /M1.
For daily+weekly reports
Syntax
RO p1,p2,p3
p1: Report type (DAY+WEEK)
p2: Day of creation (SUN, MON, TUE, WED,
THU, FRI, SAT)
p3: Hour of creation (hh fixed form)
hhHour (00 to 23)
Query
RO?
Example
Create a daily report at 9 o’clock everyday, and a
weekly report every Tuesday.
RODAY+WEEK,TUE,09
Description This command can be used on models with the
computation function option /M1.
RM
Sets the report channel
When not using the report channel
Syntax
RM p1,p2
p1: Report channel number (01 to 30) (01 to 12
on the CX1000)
p2: Use/Not use the report channel (OFF)
Query
RM[ p1]?
Example
Set the report channel of number 1 to not used.
RM01,OFF
Description This command can be used on models with the
computation function option /M1.
When using the report channel
Syntax
RM p1,p2,p3,p4
p1: Report channel number (01 to 30) (01 to 12
on the CX1000)
p2: Use/Not use the report channel (ON)
p3: The measurement/computation channel
number on which reports are to be made
(01 to 20, 31 to 60) (01 to 06, 31 to 42 on
the CX1000)
p4: Summation conversion of the waveform on
which integration is to be performed
OFF
No conversion
/S
Convert as though the physical
values are integrated in units of
seconds.
/MIN
Convert as though the physical
values are integrated in units of
minutes.
/H
Convert as though the physical
values are integrated in units of
hours.
/DAY
Convert as though the physical
values are integrated in units of
days.
Query
RM[ p1]?
Example
Use the report channel number 1. Set the
measurement/computation channel number on
which reports are to be made to 01, and the
summation conversion of the waveform on which
integration is to be performed to 1 s.
RM01,ON,01,/S
Description • This command can be used on models with
the computation function option /M1.
• About p4
Because the sampled data are integrated over
each scan interval, the physical value
integrated over a given period may be
different from the actual integrated value.
This occurs if the given period is not equal to
the scan interval. In these cases, set p4 to
the unit of the integration time desired. The
integrated value is found according to the
following conversion equations that depend
on the parameter.
OFF
Σ(Measured value)
/S
Σ(Measured value) × scan interval
/MIN
Σ(Measured value) × scan interval/
60
/HOUR
Σ(Measured value) × scan interval/
3600
/DAY
Σ(Measured value) × scan interval/
86400
The unit of the scan interval is seconds.
6.7 Basic Setting Commands (Measurement)
