6-50
IM 04L31A01-17E
6.8 Basic Setting Commands (Control)
MK
Burnout settings
Syntax
MK p1,p2
p1: Control input channel numbers (CI01–CI10,
or CI01–CI05 for the CX1000)
p2: Burnout settings (on/off)
Query
MK[ p1]?
Description Valid when PV/SP computation is ON.
HR
Sets the RJC
Syntax
HR p1,p2,p3,p4
p1: Loop number (1 to 6) (1 or 2 on the CX1000)
p2: Input number (1 to 3)
1: Measure 1
2: Measure 2
3: Remote
p3: RJC method (External, Internal)
p4: RJC value (–20000 to 20000)
Query
HR[ p1,p2]?
Example
Set the RJC of Loop 2 remote to external and
1000 µV.
HR2,3,EXTERNAL,1000
Description Valid when PV/SP computation is OFF.
MJ
Sets the RJC
Syntax
MJ p1,p2,p3,p4
p1: Control input channel numbers (CI01–CI10,
or CI01–CI05 for the CX1000)
p2: RJC method (External, Internal)
p3: RJC value (–20000 to 20000)
Query
MJ[ p1]?
Description Valid when PV/SP computation is ON.
Contact Input Registration/AUX
GT
Registers contact inputs
Syntax
GT p1,p2,p3
p1: Module type*
1
p2: Contact number*
2
p3: Function type*
3
*1:
CTRL1-DI, CTRL1-DO,
CTRL2-DI, CTRL2-DO,
CTRL3-DI, CTRL3-DO,
EXT1-RI, EXT1-RO, INT-SW1, INT-
SW2, INT-SW3
For the CX1000, CTRL1-DI, CTRL1-DO,
INT-SW1, INT-SW2, INT-SW3.
However,
INT-SW1:SW001-SW012
(or SW001-SW006 for the CX1000)
INT-SW2:SW013-SW024
(or SW007-SW012 for the CX1000)
INT-SW3:SW025-SW036
(or SW013-SW018 for the CX1000)
*2:
DI001 to DI006
DI101 to DI106
DI201 to DI206
RI001 to RI012 (expansion module)
SW001 to SW036 (Internal switch)
On the CX1000: DI001 to DI006,
SW001 to SW036
*3:
None
Auto1-2/3-4 (only during cascade
control)
Auto1-2 only on the CX1000
Man1-2/3-4(only during cascade control)
Man1-2 only on the CX1000
Cascade1-2/3-4 (only during cascade
control)
Cascade1-2 only on the CX1000
Auto/Man (1, 2/3, 4/5, 6 (1, 2 on the
CX1000) for each module)
ControlStart/Stop1 to 6 (1 or 2 on the
CX1000)
(1, 2/3, 4/5, 6 (1, 2 on the CX1000)
for each module)
Remote/Local1 to 6 (1 or 2 on the
CX1000)
(1, 2/3, 4/5, 6 (1, 2 on the CX1000)
for each module)
AllControlStart
AllControlStop
SPNumber0bit to 3bit (Fixed to 6 to 3 on
the control module). (Fixed to 12 to 9 on
the expansion module). (The contacts
are automatically assigned according to
the specified number of bits)
ProgramReset
ProgramRun
Hold
Advance
PatternNo0bit to 4bit (Fixed to 1 to 5
on the control module).
(Fixed to 1 to 5 on the expansion
module).
(The contacts are automatically
assigned according to the specified
number of bits)
PVSwitching1 to 4 (1 or 2 on the
CX1000) (valid only during loop
control with PV switching)
You can also specify the remote action
of the XR command. For details on the
remote action, see XR command.
Query
GT[ p1,p2]?
Example
Set the contact number 1 whose module type is
CTRL1-2 to “AllControlStart”.
GTCTRL1-2,DI001,ALLCONTROLSTART
