• Write Registers for DO/internal switches

D4501
D4502
D4503
D4504
D4505
D4506
D4507 to D4512
D4513 to D4518
D4519 to D4530
D4531 to D4600
D4601 to D4636

0: OFF, 1: ON
0: OFF, 1: ON
0: OFF, 1: ON
0: OFF, 1: ON
0: OFF, 1: ON
0: OFF, 1: ON
0: OFF, 1: ON
0: OFF, 1: ON
0: OFF, 1: ON

0: OFF, 1: ON

R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W

R/W

D Register

Number

Description

Register Type

Value

Read/

Write

DO001
DO002
DO003
DO004
DO005
DO006
DO101 to DO106
DO201 to DO206
RO001 to RO012
Reserved
SW001 to SW036
