Command
GS
Sets remote input
Syntax
GS p1,p2
p1: Loop number (1 to 6) (1 or 2 on the CX1000)
p2: Remote input
(Off, Remote)
Query
GS[ p1]?
Example
Use the remote of loop 2.
GS2,REMOTE
HG
Sets the alarm mode
Syntax
HG p1,p2
p1: Loop number (1 to 6) (1 or 2 on the CX1000)
p2: Alarm mode
(Always,Stop,Stop/Man)
Query
HG[ p1]?
Example
Set the alarm mode of loop 2 to stop.
HG2,STOP
HY
Sets the SP number selection
source
Syntax
HY p1,p2
p1: Loop number (1 to 6) (1 or 2 on the CX1000)
p2: SP number selection source (Off, On)
Example
Turn On loop 1.
HY1,ON
MY
Turns Off/On the PV/SP
computation
Syntax
MY p1
p1: PV/SP computation function Off/On
Query
MY?
MZ
Sets the CLOG error
Syntax
MZ p1
p1: CLOG error processing (skip, error)
Query
MZ?
Output Processing
GF
Sets the output processing
Syntax
GF p1,p2,p3,p4
p1: Loop number (1 to 6) (1 or 2 on the CX1000)
p2: Control output type*
p3: Cycle time (1 to 1000)
p4: Analog output-type
(4-20 mA, 0-20 mA, 20-4 mA, 20-0 mA)
*: Relay
Voltage-pulse
Current-output
On/Off-control
Query
GF[ p1]?
Example
Set the control output type of loop 4 to current
output, cycle time to 600 s, and analog output
type to 4-20 mA.
GF4,CURRENT-OUTPUT,600,4-20MA
Relay
GR
Sets relay parameters
Syntax
GR p1,p2
p1: Enable/Disable the FAIL function (Off, On)
p2: Enable/disable self diagnosis function (Off,
On)
Query
GR?
Example
Turn Off the FAIL function and turn On the self
diagnosis function
GROFF,ON
GE
Sets relay action
Syntax
GE p1,p2,p3
p1: Module type
*1
p2: Relay number
*2
p3: Relay action
*3
*1:
CTRL1-2, CTRL3-4, CTRL5-6
EXTDIO (CTRL1-2 only on the
CX1000)
*2:
DI001 to DI006
DI101 to DI106
DI201 to DI206
RI001 to RI012 (expansion module)
On the CX1000: DI001 to DI006
*3:
De_energize/Hold, De_energize/
Nonhold,
Energize/Hold, Energize/Nonhold
Query
GE[ p1,p2]?
Example
The relay number 10 of the expansion module to
“Energize/Hold”.
GEEXTDIO,RO010,ENERGIZE/HOLD
6.8 Basic Setting Commands (Control)
