9-21

IM 04L31A01-17E

Green Series Communications

Confirming or Canceling the Settings

13.

To confirm the new settings, press the DISP/ENTER key. To cancel the
settings, press the ESC key.

For a detailed procedure in confirming or canceling settings, see “Setup Procedure Using
Operation Keys” on page ix.

Saving the Settings

14.

Press the ESC key several times to display the basic setting menu.

15.

Press the [End] soft key. A dialog box appears for you to select whether to save
the settings.

16.

To save the settings, select [Yes]. To not save the settings, select [No]. To
return to the basic setting menu, select [Cancel]. Then, press the DISP/ENTER
key.

Note

To activate the settings that have been changed in the basic setting mode, the settings must be
saved. Otherwise, the settings that existed before the change are activated.

9.6 External Loop Setting > Tuning Setting
