Yokogawa Data Acquisition with PID Control CX2000 User Manual
Page 134

6-5
IM 04L31A01-17E
Command
6
Command Command Function
Execution mode
ADMINISTRATOR
USER Page
Type
Name
Event Setting
ET
Sets the time event
Operation mode
Yes
No
6-21
EP
Sets the PV event
Operation mode
Yes
No
6-22
Event Output Setting
EO
Sets the event output
Operation mode
Yes
No
6-22
PA
Program pattern end signal
Operation mode
Yes
No
6-22
Repeat Action Setting
PR
Sets the repeating action
Operation mode
Yes
No
6-22
Program End
PE
End programming
Operation mode
Yes
No
6-22
Auto message for program Run/Reset
PK
Set the auto message for program run/reset Operation mode
Yes
No
6-22
Program display position
PL
Set the program display position
Operation mode
Yes
No
6-22
Auto change to program run display
MQ
Auto change to program run display
Operation mode
Yes
No
6-22
Event display group
PV
Set the event display group
Operation mode
Yes
No
6-22
Detail Settings (Control Function Settings)
HF
Sets the setpoint
Operation mode
Yes
No
6-23
GL
Sets the output velocity limiter
Operation mode
Yes
No
6-23
GA
Sets the anti-reset windup function
Operation mode
Yes
No
6-23
Detail Settings (Hysteresis (Alarm, PV Event))
AP
Sets the alarm hysteresis
Operation mode
Yes
No
6-23
PH
Sets the PV event hysteresis
Operation mode
Yes
No
6-23
Detailed settings (DIO operation monitoring and function settings)
DX
Set the DIO operation monitoring function
Operation mode
Yes
No
6-23
DY
Set the DIO operation monitoring function
Operation mode
Yes
No
6-24
tag and tag comment
DZ
Set the DIO operation monitoring function
Operation mode
Yes
No
6-24
label and display color
Detailed settings (DI/DO label settings)
DW
Set the DI/DO label
Operation mode
Yes
No
6-24
Control computation
MT
Se the equation
Operation mode
Yes
No
6-25
MU
Se the computation error
Operation mode
Yes
No
6-25
MV
Se the logic computation
Operation mode
Yes
No
6-25
MX
Se the computation constant
Operation mode
Yes
No
6-25
DU
Se the remote bias
Operation mode
Yes
No
6-25
External Loop Setting (PID Parameter)
DT
Sets the external loop PID parameter
Basic setting mode
Yes
No
6-26
External Loop Setting (Control Parameter)
DV
Sets the external loop control parameter
Basic setting mode
Yes
No
6-26
Yes: Command usable
No: Command not usable
6.2 A List of Commands
