Yokogawa Data Acquisition with PID Control CX2000 User Manual
Page 290

App-31
IM 04L31A01-17E
App
Appendix
Parameters Related to Loop 1
D1001
D1002
D1003
D1004
D1005
D1006
D1007
D1008
D1009
D1010
D1011
D1012
D1013
D1014
D1015
D1016
D1017
D1018
D1019
Parameter
per Loop
Enable/Disable the use of bias on
PV1, bias value, bias input type
Enable/Disable the use of bias on
PV2, bias value, bias input type
Enable/Disable the use of bias on
RemoteSP, bias value
Type of filter used on PV1,
enable/disable the use of the
filter, filter value
Type of filter used on PV2,
enable/disable the use of the
filter, filter value
Type of filter used on RemoteSP,
enable/disable the use of the
filter, filter value
Enable/Disable ratio setting and
the ratio value
Suppressing function On/Off
Ramp-rate-time unit
SP ramp-up-rate
SP ramp-down-rate
Switch between auto, manual,
and cascade control
SP number
Switch run/stop
Remote/local switching
Currently used PID number
OUT value in manual mode
Auto tuning (AT) status
Decimal point position of ratio
value
–100% to 100% of the measurement span:
Bias value (bias enabled)
–30001 to –32768, 30001 to 32767:
Bias disabled
–100% to 100% of the measurement span:
Bias value (bias enabled)
–30001 to –32768, 30001 to 32767:
Bias disabled
–100% to 100% of the measurement span:
Bias value (bias enabled)
–30001 to –32768, 30001 to 32767:
Bias disabled
1 to 120: Filter value (filter enabled)
–30001 to –32768, 30001 to 32767:
Filter disabled
1 to 120: Filter value (filter enabled)
–30001 to –32768, 30001 to 32767:
Filter disabled
1 to 120: Filter value (filter enabled)
–30001 to –32768, 30001 to 32767:
Filter disabled
1 to 9999: ratio value (ratio setting enabled)
–30001 to –32768, 30001 to 32767:
Ratio setting disabled
0: Suppressing function OFF
1: Suppressing function ON
0: Hour 2: Second
1: Minute
Value between 1 and the maximum value of
the measurement span excluding the
decimal point.
–30001 to –32768, 30001 to 32767:
OFF
Value between 1 and the maximum value of
the measurement span excluding the
decimal point.
–30001 to –32768, 30001 to 32767:
OFF
0: Auto switching
1: Manual switching
2: Cascade switching (valid only during
cascade control)
1 to 8: SP number
0: Stop
1: Start
0: Local
1: Remote
1 to 8: PID number
–50 to 1050: –5.0% to 105.0%
0: AT not in progress
1: AT in progress
0 to 4
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R
R/W
R
R/W
D Register
Number
Description
Register
Type
Value
Read/
Write
Appendix 6 Register Assignments
