Program Operatin Mode Output
• The FH command is used to output the data.
• The status of the program operation mode is output. The status is indicated using 32
bits that are divided into 4 groups of 8 bits.
Syntax
EA
CRLF
xxx.xxx.xxx.xxx
CRLF
EN
CRLF
xxx
The statuses of bits 31 to 24, 23 to 16, 15 to 8, and 7 to 0 are indicated
in order in decimal notation.
31
0
1
2
Bit
The status of each bit indicates the status of the program operation
mode.
Bit 0 status
0: reset, 1: Frun
Bit 1 status
0: Not holding, 1: Holding
Bit 2 status
0: Not waiting, 1: Waiting
Example
When not waiting, not holding, and reset
EA
000.000.000.000
EN
Output of Program Pattern Information Currently in Execution
• The FJ command is used to output the data.
• The information about the program pattern that is currently in execution is output.
Syntax
EA
CRLF
PTNO_x1
CRLF
SEGNO_x2
CRLF
PRE_SEGNO_x3
CRLF
SEGUSE_x4
CRLF
SEGTM_hh:mi:ss
CRLF
WAITTM_hh:mi:ss
CRLF
RCYMOD_x5
CRLF
ALL_RCY_x6
CRLF
REM_RCY_x7
CRLF
RST_x8
CRLF
REN_x9
CRLF
PTN_START_DATE_yy/mo/dd
CRLF
PTN_START_TIME_hh:mi:ss
CRLF
PTN_STOP_DATE_yy/mo/dd
CRLF
PTN_STOP_TIME_hh:mi:ss
CRLF
EN
CRLF
